MODICON MICRO PCMCIA CARD TYPE III - FOR ATRIUM CO-PROCESSOR/PREMIUM PROCESSOR - RS485
| Part Number | TSXSCP114 |
| Manufacturer | Schneider Electric |
| Type | CPUs |
| Model # | TSX-SCP-114 |
| Warranty | 2 Year |
| Range of product | Modicon Premium Automation platform |
| Accessory / separate part category | Communication accessories |
| Accessory / separate part type | PCMCIA card |
| Product compatibility | TSX37-21/22 |
| TSXSCY21601 | |
| Accessory / separate part destination | Atrium co-processor |
| Premium processor | |
| Memory type | PCMCIA card type III |
| Physical interface | RS485 |
| Communication port protocol | Character mode |
| Modbus |
| Uni-Telway | |
| Current consumption | 150 mA 5 V DC |
| Product weight | 0.105 kg |
| Sustainable offer status | Green Premium product |
| RoHS (date code: YYWW) | Compliant - since 0950 - Schneider Electric declaration of conformity |
| Product environmental profile | Available |
| Product end of life instructions | Available |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TSXSCP114 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TSXSCP114 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TSXSCP114, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty TSXSCP114 for credit when ordering from MRO Electric
The Schneider Electric TSXSCP114 is a PCMCIA communication card designed for seamless integration within the Modicon Premium Automation platform. As a crucial component for industrial automation, this card enhances communication capabilities, allowing efficient data exchange between controllers and connected devices. Built with compatibility, the TSXSCP114 supports various protocols, including Modbus, Uni-Telway, and character mode, ensuring versatile connectivity for different industrial applications.
The TSXSCP114 is a Type III PCMCIA card that provides RS485 communication and is engineered to work with multiple devices, including the TSX37-21/22 controllers and TSXSCY21601 modules. Whether used in Atrium co-processors or Premium processors, this card ensures reliable, high-speed data transmission, making it an essential accessory for optimizing industrial automation systems.
One of the key advantages of the Schneider Electric TSXSCP114 is its ability to support multiple communication protocols. With built-in Modbus, Uni-Telway, and character mode communication, this card enables flexible integration with a wide range of automation devices. The RS485 physical interface allows for robust, long-distance communication while minimizing signal interference, ensuring accurate and stable data transmission.
This PCMCIA card is designed to function within Schneider Electric's Modicon Premium platform, providing enhanced communication for connected processors and co-processors. Its compatibility with various automation components makes it a valuable addition to new and existing industrial control systems.
The TSXSCP114 is designed for efficiency, with a low power consumption of 150 mA at 5 V DC. This ensures minimal energy usage while maintaining optimal performance in demanding industrial environments. As a Green Premium product, the TSXSCP114 adheres to Schneider Electric's environmental and sustainability standards, meeting the RoHS compliance regulations since 0950.
Additionally, the product's environmental profile and end-of-life instructions are readily available, allowing businesses to make informed decisions regarding sustainability practices. This ensures that the TSXSCP114 is a reliable and environmentally responsible choice for industrial communication.
Weighing just 0.105 kg, the Schneider Electric TSXSCP114 is lightweight and compact, making it easy to install and integrate within automation systems. Its PCMCIA form factor allows for quick and secure insertion into compatible devices, reducing setup time and ensuring a hassle-free installation process.
For industries that require immediate replacement or new installations, the Schneider Electric TSXSCP114 is available for immediate shipping from MRO Electric and Supply. Each unit comes with free shipping and a 2-year warranty, ensuring customers receive high-quality, reliable automation components backed by expert support.
What is the Schneider Electric TSXSCP114 used for?
It is a PCMCIA communication card designed to enhance data exchange in Modicon Premium automation systems.
What communication protocols does this card support?
The TSXSCP114 supports Modbus, Uni-Telway, and character mode communication.
Which devices are compatible with the TSXSCP114?
It is compatible with TSX37-21/22 controllers, TSXSCY21601 modules, Premium processors, and Atrium co-processors.
What is the physical interface of this communication card?
The TSXSCP114 uses an RS485 interface, ensuring reliable and long-distance communication.
What is the power consumption of the TSXSCP114?
It operates at 150 mA at 5 V DC, making it an energy-efficient choice.
Is the TSXSCP114 RoHS compliant?
It has been RoHS compliant since 0950, following Schneider Electric's environmental regulations.
How much does the TSXSCP114 weigh?
The card weighs 0.105 kg, making it lightweight and easy to install.
Is this communication card a Green Premium product?
It is classified as a Green Premium product, adhering to Schneider Electric's sustainability standards.
Where can I purchase the TSXSCP114?
It is available through MRO Electric and Supply, with free shipping and a 2-year warranty.
How can I ensure the proper installation of this PCMCIA card?
Follow the manufacturer's guidelines to insert the Type III PCMCIA card into the compatible slot of your automation controller or processor.
