TSXPSY5500

2-year Warranty

Same Day Shipping

Schneider Electric TSXPSY5500

MODICON PREMIUM POWER SUPPLY MODULE - 24 V DC - 500/1700 MA - 19 W

5/5
3 ratings

5 in stock


Free Shipping

2 Year warranty

Part NumberTSXPSY5500
ManufacturerSchneider Electric
TypePower Supplies
Model #TSX-PSY-5500
Warranty2 Year
RangeModicon Premium Automation
CategoryTSX Premium
DescritpionPower supply module
Rated voltage100...120 V AC 85...140 V 200...240 V AC 190...264 V
Frequency50/60 Hz
I²t on activation2 A².s 240 V 4 A².s 100 V
Input current1700 mA 100 V 500 mA 240 V
Network frequency limits47…63 Hz
Secondary power19 W 24 V DC 35 W 5 V DC
MarkingCE
Inrush current38 A 100 V 38 A 240 V
ProtectionInternal fuse 4 A 5 x 20 mm time-delayed primary circuit Overload protection secondary circuit Overvoltage protection secondary circuit Short-circuit protection secondary circuit
Format Double
Signalling1 LED (green) for presence of sensor voltage (24V) 1 LED (green) for presence of voltages (OK) 1 LED (red) for battery fault (BAT)
Insulation resistance>= 100 MOhm primary/ground >= 100 MOhm primary/secondary
Immunity to microbreaks10 ms
CertificationsRMRS, LR, ABS, GL, RINA, DNV, BV
Standards73/23/EEC CSA C22.2 No 142 CSA C22.2 No 213 Class I Division 2 Group C 92/31/EEC UL 508 CSA C22.2 No 213 Class I Division 2 Group D CSA C22.2 No 213 Class I Division 2 Group B CSA C22.2 No 213 Class I Division 2 Group A IEC 61131-2 89/336/EEC 93/68/EEC
Ambient temp0…60 °C
Operating altitude0...2000 m
ProtectionIP20

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed TSXPSY5500 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this TSXPSY5500 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty TSXPSY5500, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 18 hours and 54 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty TSXPSY5500 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric TSXPSY5500 Overview

Schneider Electric TSXPSY5500 Power Supply Module

Overview: TSXPSY5500M - Modicon Premium Automation Platform

The Schneider Electric TSXPSY5500 power supply module is a cornerstone within the Modicon Premium Automation platform, designed to deliver precise and reliable power in industrial automation environments. This robust module, designated as TSXPSY5500M, stands as a testament to Schneider Electric's commitment to excellence in power supply technology.

Key Specifications

Operating seamlessly within a voltage range of 100 to 120 V AC (85 to 140 V) and 200 to 240 V AC (190 to 264 V), the TSXPSY5500 caters to diverse power input requirements. The network frequency versatility spans 50/60 Hz with limits of 47 to 63 Hz. With an input current of 1700 mA at 100 V and 500 mA at 240 V, this module ensures efficient power utilization.

Protection Mechanisms

The TSXPSY5500 incorporates a comprehensive suite of protection features. An internal fuse, rated at 4 A and 5 x 20 mm time-delayed, secures the primary circuit. Overload, overvoltage, and short-circuit protection fortify the secondary circuit, ensuring the longevity and reliability of connected devices. Inrush current is intelligently managed, reaching 38 A at both 100 V and 240 V.

Power Output and Secondary Voltage Distribution

Delivering a total useful secondary power of 50 W, the TSXPSY5500 allocates 19 W at 24 V DC and 35 W at 5 V DC. The secondary voltage distribution caters to diverse applications, with 0.8 A each for 24 V DC relay and sensor power supply, and 7 A for 5 V DC.

Insulation and Resistance

The insulation resistance exceeds 100 MOhm for both primary/ground and primary/secondary, ensuring a stable and secure electrical environment. This insulation proficiency safeguards against potential electrical hazards, contributing to the module's longevity.

Indicators and Signaling

Equipped with three LEDs, the TSXPSY5500 provides operational visibility. A green LED signifies the presence of sensor voltage (24V), another green LED indicates the overall status of voltages (OK), and a red LED alerts to battery faults (BAT). These indicators enhance troubleshooting efficiency and contribute to seamless operation.

Environmental Resilience

The TSXPSY5500 thrives in demanding industrial environments. Operating within an ambient air temperature range of 0 to 60 °C, with a storage temperature range of -25 to 70 °C, it is engineered to endure diverse operational conditions. The module exhibits an immunity to microbreaks within 10 ms and maintains a dielectric strength of 2000 V for both primary/earth and primary/secondary.

Compliance and Certification

Compliant with standards such as 73/23/EEC, CSA C22.2, UL 508, IEC 61131-2, and more, the TSXPSY5500 adheres to stringent industry benchmarks. Certifications from RMRS, LR, ABS, GL, RINA, DNV, and BV underscore its reliability and adherence to international marine and industrial standards.

TSXPSY5500 - Precision, Protection, and Performance

In conclusion, the Schneider Electric TSXPSY5500 power supply module emerges as a technological marvel within the Modicon Premium Automation platform. From its precise voltage and current management to its robust protection mechanisms and environmental resilience, every facet of this module is meticulously designed for optimal performance. As industries evolve, the TSXPSY5500 stands ready to meet the dynamic demands of modern automation, providing a reliable and efficient power supply solution for industrial applications.

FAQ for Schneider Electric TSXPSY5500 Power Supply Module

What is the input voltage range for the TSXPSY5500 power supply module?

The TSXPSY5500 supports an input voltage range of 100-120V AC (85-140V) and 200-240V AC (190-264V).

What is the rated frequency for this power supply module?

It operates at 50/60 Hz, with network frequency limits of 47–63 Hz.

What are the power outputs of the TSXPSY5500?

The module provides:

  • 19W at 24V DC
  • 35W at 5V DC

Does the TSXPSY5500 have built-in protection features?

Yes, it includes:

  • Internal fuse (4A, 5x20 mm, time-delayed) in the primary circuit
  • Overload, overvoltage, and short-circuit protection in the secondary circuit

What certifications does this module have?

It is certified by multiple regulatory bodies, including:

  • RMRS, LR, ABS, GL, RINA, DNV, BV
  • UL 508, CSA C22.2, IEC 61131-2, and several EU directives (73/23/EEC, 92/31/EEC, 89/336/EEC, 93/68/EEC).

What is the maximum inrush current?

The inrush current is 38A at both 100V and 240V.

How does the TSXPSY5500 indicate its status?

It has three LEDs:

  • Green LED for sensor voltage presence (24V)
  • Green LED for overall voltage presence (OK)
  • Red LED for battery fault (BAT)

What is the insulation resistance of this power supply?

It has an insulation resistance of ≥100 MΩ between:

  • Primary and ground
  • Primary and secondary circuits

What is the operating temperature range?

The module operates in temperatures from 0 to 60°C.

What is the maximum operating altitude?

The TSXPSY5500 can function at altitudes up to 2000 meters.

Let me know if you need more details!

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Power Supplies from other manufacturers such as Modicon and ABB.

Contact Us Today For More Information About Schneider Electric Products

Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like TSXPSY5500, take a look at more from our Power Supplies line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our TSXPSY5500 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
