Schneider Electric TSXPCX1031

Schneider Electric TSXPCX1031 Connecting Cable

The Schneider Electric TSXPCX1031 connecting cable is a robust and reliable accessory designed to facilitate seamless communication between various automation platforms and terminals. This 2.5-meter RS232 connecting cable is compatible with a range of Schneider Electric products, including the Magelis GTO, TSX Micro, Twido, and Modicon Premium automation platforms and the Magelis XBT series. The TSXPCX1031 is engineered to ensure reliable data transfer across diverse applications, making it an essential component in modern industrial setups.

Comprehensive Connectivity and Compatibility

The TSXPCX1031 connecting cable has two types of electrical connectors: a female mini-DIN 8-pin connector and a female SUB-D 9 connector. This configuration allows users to connect the cable with various terminals and devices efficiently. Additionally, the kit includes a SUB-D 9-way female to 25-way male adaptor, providing extra versatility for integration with additional Schneider Electric devices. The TSXPCX1031 supports key communication protocols such as Modbus, Character Mode, and Uni-Telway, widely used in industrial automation environments. This extensive protocol support makes the TSXPCX1031 suitable for data communication and control applications, offering high adaptability across various automation needs.

Reliable Physical Interface and Performance

This Schneider Electric connecting cable is compatible with RS232 and RS485 physical interfaces, enhancing its functionality and supporting short—and long-range data transmissions. Its robust RS232 interface facilitates efficient, low-cost serial communication over short distances, which is ideal for reliable data exchange between connected devices. The RS485 interface, known for its high resilience against electromagnetic interference, ensures stable data communication even in industrial environments with high levels of electrical noise.

Green Premium Product with Sustainable Design

As a Green Premium product, the Schneider Electric TSXPCX1031 is designed to meet environmental standards. Schneider Electric has ensured that this accessory complies with RoHS requirements, thus reducing hazardous substances and supporting eco-friendly operations. Additionally, the TSXPCX1031 has a comprehensive Product Environmental Profile, and its end-of-life instructions highlight that the product requires no specific recycling operations, making it easier for users to dispose of it responsibly at the end of its lifecycle.

Lightweight and Easy to Install

Weighing only 0.17 kg, the TSXPCX1031 connecting cable is lightweight, compact, and easy to install. This feature, combined with its high durability, makes it an ideal choice for users looking for a low-maintenance and effective solution for data communication in industrial settings. The compact design and 2.5-meter cable length also allow flexible placement, enabling users to connect distant devices without compromising communication speed or reliability.

Warranty and Shipping Benefits

Schneider Electric offers a 2-year warranty for the TSXPCX1031 connecting cable when purchased from MRO Electric and Supply, ensuring reliability and peace of mind for users. Furthermore, MRO Electric and Supply provides free shipping, adding value and convenience for customers seeking a cost-effective solution for their automation needs.

FAQs

1. What devices are compatible with the Schneider Electric TSXPCX1031 connecting cable?

The TSXPCX1031 is compatible with a range of Schneider Electric products, including the Magelis GTO, TSX Micro, Twido, Modicon Premium automation platform, and Magelis XBT series. This compatibility makes it versatile for various industrial automation systems.

2. What is the cable length of the TSXPCX1031, and is it sufficient for most industrial applications?

The cable length is 2.5 meters, which is generally sufficient for connecting devices in most industrial settings. It supports flexible device positioning without compromising communication reliability.

3. Does the TSXPCX1031 support RS485 communication?

Yes, the TSXPCX1031 supports RS232 and RS485 physical interfaces, allowing it to handle short- and long-range data transmission needs, even in environments with high electrical noise.

4. What communication protocols does this cable support?

The TSXPCX1031 supports Modbus, Character Mode, and Uni-Telway protocols, widely used in industrial automation for communication and control purposes.

5. Is the TSXPCX1031 environmentally friendly?

Yes, it is classified as a Green Premium product. It adheres to RoHS compliance and features an environmental profile that requires no specific recycling actions at end-of-life.

6. What is included in the TSXPCX1031 kit?

The kit includes one connecting cable and SUB-D 9-way female to the 25-way male adaptor, offering additional connectivity options for Schneider Electric devices.
