| Part Number | TSXP574634M |
| Manufacturer | Schneider Electric |
| Type | CPUs |
| Model # | TSX-P57-4634M |
| Warranty | 2 Year |
| Module format | Double |
| Product or component type | Unity processor |
| Number of racks | 8 12 slots |
| 16 4/6/8 slots | |
| Discrete I/O processor capacity | 2040 I/O |
| Analogue I/O processor capacity | 256 I/O |
| Number of application specific channel | ≤ 64 |
| Number of process control channel | ≤ 20 up to 60 simple loops |
| Integrated connection type | Ethernet TCP/IP RJ45 |
| USB port 12 Mbit/s | |
| Serial link female mini DIN RS485 19.2 kbit/s | |
| Communication module processor | 1 |
| 3 | |
| 4 | |
| 8 | |
| Memory description | PCMCIA card 16384 kB additional data storage |
| Internal RAM (with PCMCIA card) 2048 kB program | |
| Internal RAM (with PCMCIA card) 440 kB data | |
| Internal RAM (without PCMCIA card) 440 kB program and data | |
| Software designation | Unity Pro |
| Protective treatment | TC |
| Concept | Transparent Ready |
| Number of slots | ≤ 128 |
| Port Ethernet | 10BASE-T/100BASE-TX |
| Maximum size of object areas | 64 %KWi constant words located internal data |
| 64 %MWi internal words located internal data | |
| 32768 %Mi located internal bits | |
| Unlimited (DFB and EFB function blocks) unlocated internal data | |
| Unlimited (elementary and derived data) unlocated internal data | |
| Application structure | 1 fast task |
| 1 master task | |
| 64 event tasks | |
| Execution time per instruction | 0.039...0.057 µs Boolean without PCMCIA card |
| 0.048...0.057 µs Boolean with PCMCIA card | |
| 0.054...0.073 µs word or fixed-point arithmetic without PCMCIA card | |
| 0.054...0.073 µs word or fixed-point arithmetic with PCMCIA card |
| 0.55...0.63 µs floating points without PCMCIA card | |
| 0.55...0.63 µs floating points with PCMCIA card | |
| Number of instructions per ms | 11.4 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card |
| 11.4 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card | |
| 15.75 Kinst/ms 100 % Boolean without PCMCIA card | |
| 15.75 Kinst/ms 100 % Boolean with PCMCIA card | |
| System overhead | 0.08 ms fast task |
| 1 ms master task | |
| Marking | CE |
| Local signalling | 1 LED green processor running (RUN) |
| 1 LED red processor or system fault (ERR) | |
| 1 LED red I/O module or configuration fault (I/O) | |
| 1 LED yellow activity on TER or AUX terminal port (TER) | |
| 1 LED green Ethernet TCP/IP port ready (RUN) | |
| 1 LED red Ethernet TCP/IP port fault (ERR) | |
| 1 LED red collision detection (COL) | |
| 1 LED yellow Ethernet link diagnostics (STS) | |
| 1 LED yellow transmission activity (TX) | |
| 1 LED yellow reception activity (RX) | |
| Current consumption | 1880 mA 5 V DC |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TSXP574634M to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TSXP574634M we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TSXP574634M, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty TSXP574634M for credit when ordering from MRO Electric
The TSXP574634M is a powerful Unity processor manufactured by Schneider Electric. It is designed to streamline automation processes and enhance operational efficiency in industrial environments. With its advanced features and robust design, this processor offers seamless integration and reliable performance for diverse applications.
Featuring a double module format, the TSXP574634M Unity processor provides flexibility and scalability in system configuration. It supports up to 8 racks with 12 slots or 16 racks with 4/6/8 slots, allowing for versatile deployment options to meet specific automation requirements.
This Unity processor has extensive discrete and analog I/O processor capacity, supporting up to 2040 discrete I/O and 256 analog I/O channels. This high capacity enables handling complex automation tasks and facilitates the integration of multiple sensors and actuators.
The TSXP574634M Unity processor has integrated communication interfaces, including Ethernet TCP/IP RJ45, USB port (12 Mbit/s), and serial link female mini-DIN RS485 (19.2 kbit/s). These interfaces enable seamless connectivity with external devices and networks, facilitating data exchange and system integration.
With a PCMCIA card offering 16384 kB of additional data storage and internal RAM of 2048 kB for the program and 440 kB for data, the TSXP574634M provides ample memory capacity for storing application logic and data. It is compatible with Unity Pro software, offering a comprehensive development environment for programming and configuring automation systems.
Built on the Transparent Ready concept, this Unity processor ensures compatibility and interoperability with other Schneider Electric devices and systems. It supports transparent communication protocols, allowing seamless data exchange and integration within the automation ecosystem.
The TSXP574634M Unity processor has comprehensive local signaling indicators, including LEDs for processor status (RUN/ERR), I/O module status, Ethernet TCP/IP port status, and communication activity. This allows for real-time monitoring of system operation and facilitates quick diagnostics of faults or errors.
With fast execution times per instruction and high instruction processing rates, the TSXP574634M Unity processor delivers optimized performance for automation tasks. It offers rapid Boolean, arithmetic, and floating-point operations, ensuring efficient execution of control algorithms and logic.
A: The TSXP574634M is a Unity Processor manufactured by Schneider Electric, designed for automation and control applications in industrial settings.
A: The Unity Processor offers a double module format, high I/O processor capacity, integrated communication interfaces, ample memory, and compatibility with Unity Pro software.
A: The processor is suitable for various automation tasks in industries such as manufacturing, process control, infrastructure, and more.
A: It provides seamless integration, reliable performance, and rapid execution times for automation tasks, improving efficiency and productivity.
A: The processor features Ethernet TCP/IP RJ45, USB port (12 Mbit/s), serial link female mini-DIN RS485 (19.2 kbit/s) interfaces for connectivity with external devices and networks.
A: It is built on the Transparent Ready concept, ensuring compatibility and interoperability with other Schneider Electric devices and systems.
A: It comes with comprehensive local signaling indicators, including LEDs for processor status, I/O module status, Ethernet TCP/IP port status, and communication activity, allowing for real-time monitoring and quick diagnostics.
A: The processor is compatible with Unity Pro software, providing a comprehensive development environment for programming and configuring automation systems.
A: The processor currently consumes 1880 mA at 5 V DC, ensuring efficient power usage in industrial applications.
A: Technical specifications, documentation, and support materials are available through Schneider Electric's official channels and authorized distributors.
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like TSXP574634M, take a look at more from our CPUs line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our TSXP574634M products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
