Schneider Electric TSXETG100 Ethernet Modbus Gateway/Router Overview

Introduction:

The Schneider Electric TSXETG100 represents a pivotal advancement in communications technology, serving as a versatile Ethernet Modbus gateway/router. Designed to seamlessly integrate with a wide range of industrial products compatible with the Modbus standard, this device offers unparalleled connectivity and communication capabilities.

Operating System Compatibility:

Compatible with various operating systems including Windows XP Professional, Windows Vista Business and Enterprise Edition, Windows Server 2008 R2, Windows 7 Business and Enterprise Edition, and Windows Server 2003, the TSXETG100 ensures seamless integration into diverse industrial environments.

Product Concept: Transparent Ready

The TSXETG100 embodies the concept of Transparent Ready connectivity, facilitating effortless integration and communication between connected devices. Its intuitive design and robust functionality streamline networking processes, enabling efficient data exchange and control across industrial systems.

Web Server and Services:

Equipped with a Class B10 web server, the TSXETG100 offers convenient access to predefined web pages for diagnostics on Ethernet and Modbus links. Users can effortlessly monitor connected products, read Modbus device registers, and access communication services such as BOOTP protocol and SNMP agent administration.

Communication Capabilities:

Featuring an integrated Ethernet TCP/IP RJ45 connection with 10/100 Mbps capability and a 5-way removable terminal block for Modbus RTU and ASCII RS485 serial links, the TSXETG100 ensures robust and reliable communication across networks. Serial link micro switches and RJ45 RS232 ports further enhance communication flexibility.

Security Features:

The TSXETG100 is equipped with built-in security features, including a miniature onboard firewall with IP address filtering and password protection. These features safeguard against unauthorized access and ensure data integrity and confidentiality in industrial networks.

Power Supply and Mounting Support:

Powered by a 24V DC-rated supply voltage, the TSXETG100 offers flexibility in power options, including Power over Ethernet (PoE) IEEE 802.3af compatibility. Its symmetrical DIN rail mounting support facilitates easy installation in industrial control panels and enclosures.

Device Management and Monitoring:

With support for SNMP agent administration, device management becomes streamlined, allowing for centralized monitoring and control of connected devices. The TSXETG100 enables read/write access to Modbus registers of connected devices, enhancing operational efficiency and control.

Physical Dimensions and Mounting:

Measuring 72mm in width and 81mm in height, the compact design of the TSXETG100 allows for space-efficient installation in industrial environments. Its symmetrical DIN rail mounting support ensures secure and stable positioning within control panels.

Frequently Asked Questions (FAQ):

1. What is the primary function of the Schneider Electric TSXETG100 Ethernet Modbus Gateway/Router?

The TSXETG100 serves as a gateway/router, facilitating seamless communication between industrial products compatible with the Modbus standard over Ethernet networks.

2. What operating systems is the TSXETG100 compatible with?

The TSXETG100 is compatible with various operating systems, including Windows XP Professional, Windows Vista Business and Enterprise Edition, Windows Server 2008 R2, Windows 7 Business and Enterprise Edition, and Windows Server 2003.

3. What is the concept of "Transparent Ready" connectivity?

"Transparent Ready" connectivity embodies the seamless integration and communication capabilities of the TSXETG100, ensuring effortless data exchange and control between connected devices in industrial systems.

4. What communication services does the TSXETG100 offer?

The TSXETG100 provides access to predefined web pages for diagnostics, supports protocols such as BOOTP and SNMP for device administration, and facilitates read/write access to Modbus registers of connected devices.

5. How does the TSXETG100 ensure network security?

The TSXETG100 features a miniature onboard firewall with IP address filtering and password protection, safeguarding against unauthorized access and ensuring data integrity and confidentiality.

6. Can the TSXETG100 be powered using Power over Ethernet (PoE)?

Yes, the TSXETG100 is compatible with Power over Ethernet (PoE) IEEE 802.3af, providing flexibility in power options for industrial installations.

7. How is device management and monitoring facilitated with the TSXETG100?

With support for SNMP agent administration, the TSXETG100 enables centralized monitoring and control of connected devices, enhancing operational efficiency and control.

8. What mounting options are available for the TSXETG100?

The TSXETG100 is designed for symmetrical DIN rail mounting support, ensuring secure and stable positioning within industrial control panels and enclosures.

9. Can the TSXETG100 be integrated with other industrial networking components?

Yes, the TSXETG100 is designed to seamlessly integrate with other Schneider Electric and third-party industrial networking components, enabling comprehensive networking and control solutions for industrial applications.
