Schneider Electric TSX-PAC-C01

MODICON PREMIUM TERMINAL ISOLATION BOX (TSXPACC01) (TSX-PAC-C01)

Available


Free Shipping

2 Year warranty

Part NumberTSX-PAC-C01
ManufacturerSchneider Electric
TypeI/O Modules
Model #TSXPACC01
Warranty2 Year
Accessory / separate part categoryConnection accessories
Accessory / separate part typeConnection box
Accessory / separate part designationTerminal port connection box
Accessory / separate part destinationSerial connection > 10 m
Cable length1 m
Product specific applicationIsolation of signals and line termination adaptation
Range compatibilityModicon Premium automation platform
Magelis XBT
Electrical connection1 connector mini DIN
Communication port protocolCharacter mode
Uni-Telway
Physical interfaceRS485
Current consumption150 mA 5 V DC
Product weight0.69 kg
Sustainable offer statusNot Green Premium product
RoHS (date code: YYWW)Will not be compliant
