DISCRETE I/O MODULE M238 - 4 INPUTS 24 V DC - 4 OUTPUTS RELAY- 1 TERMINAL BLOCK
1 in stock
Ships Today
Free Shipping
2 Year warranty
| Part Number | TM2DMM8DRT |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Warranty | 2 Year |
| Product weight | 0.14 kg |
| Range of product | Modicon M238 logic controller |
| Product or component type | Discrete I/O module |
| Discrete input number | 4 |
| Discrete input voltage | 24 V |
| Discrete input voltage type | DC |
| Discrete output number | 4 |
| Discrete output type | Relay |
| Range compatibility | Advantys OTB |
| Twido | |
| Input voltage limits | 20.4...28.8 V |
| Discrete input logic | Sink or source |
| Discrete input current | 7 mA |
| Input impedance | 3.4 kOhm |
| Discrete output function | 1 NO |
| Current per channel | 2...5 A |
| Current per output common | 7 A |
| Number of common point | 1 for input |
| 1 for output | |
| Contact resistance | <= 45 mOhm |
| Response time | <= 10 ms from state 0 to state 1 output |
| <= 5 ms from state 1 to state 0 output | |
| 4 ms at state 0 input | |
| 4 ms at state 1 input | |
| Minimum switching current | 0.1 mA 0.1 V DC |
| Isolation between channels | None |
| Isolation between channels and | 2300 V for 1 minute (output) |
| internal logic | 500 V for 1 minute (input) |
| Isolation between input channels and | 1500 V for 1 minute |
| Isolation between output channels | 1500 V for 1 minute |
| Mechanical durability | 20000000 cycles |
| Electrical durability | 100000 cycles 0.5 A AC-15 240 V AC cos phi = 0.35 inductive |
| 100000 cycles 1 A AC-15 240 V AC cos phi = 0.7 inductive | |
| 100000 cycles 1 A DC-13 24 V DC inductive (L/R = 7 ms) | |
| 100000 cycles 2 A 240 V AC resistive | |
| 100000 cycles 2 A 30 V DC resistive | |
| Current consumption | 20 mA 24 V DC at state 1 for all input/output |
| 25 mA 5 V DC at state 1 for all input/output | |
| Local signalling | 1 display block |
| Electrical connection | 1 removable screw terminal block |
| Mounting support | 35 mm symmetrical DIN rail |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed TM2DMM8DRT to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this TM2DMM8DRT we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty TM2DMM8DRT, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty TM2DMM8DRT for credit when ordering from MRO Electric
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like TM2DMM8DRT, take a look at more from our I/O Modules line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our TM2DMM8DRT products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
