SIGMA 2 SINGLE-PHASE - 4.4A, 750W, 200V, 0.75KW SERVO MOTOR
| Part Number | SGMAH-08AAF41 |
| Manufacturer | Yaskawa |
| Type | AC Motors |
| Model # | SGMAH08AAF41 |
| Warranty | 2 Year |
| kW | 0.75 KiloWatts |
| Voltage | 200 VAC |
| Rated Speed | 3,000 RPM |
| Max Speed | 5,000 RPM |
| Mounting Type | Flange Mount |
| Encoder Type | Incremental |
| IP Rating | IP55 |
| Encoder Bit Resolution | 13 BIT |
| Constant Torque (Nm) | 2.39 |
| Peak Torque (Nm) | 7.1 |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed SGMAH-08AAF41 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this SGMAH-08AAF41 we also repair a wide range of other Yaskawa products, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty SGMAH-08AAF41, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty SGMAH-08AAF41 for credit when ordering from MRO Electric
The Sigma II compact motor module SGMAH-08AAF41 is a single phase, 200 V unit that is manufactured by Yaskawa. The SGMAH-08AAF41 is a servo motor with a rated output of 750 W, 200 V, and 4.4 A. The rated motor speed for the Yaskawa SGMAH-08AAF41is 2.39 Nm with 3000 rotations per minute. The rated output and rated motor speed are located on the label of the Yaskawa Sigma II motors for your convenience.
A few manufacturing considerations went into the design of the Sigma II motor series. The Yaskawa SGMAH-08AAF41 servo motor is designed to be a more diminutive motor; therefore, the installation process is made easier. This not only saves time but is a space consideration. The size is also designed to be a space-saving feature for the SGMAH-08AAF41. This Yaskawa Sigma II servo motor has a high power rating. This is accomplished by lessening the inertia of the motor. Lessening inertia of the motor increases the acceleration/deceleration rate and shortens positioning time.
The maximum rotation speed for the Yaskawa SGMAH-08AAF41 is 5000rpm and this Sigma II servo motor has a rated speed of 3000rpm. It has a standard 13-bit incremental encoder with an optional 16-bit encoder.
The dimensions of the Yaskawa servo motor module SGMAH-08AAF41 are as follows. The motor height is 3.15 inches, the width of the motor is 7.28 inches, and the depth of the motor module is 3.15 inches.
The servo motor component is completely enclosed in a metal casing. This servomotor module has an IP rating of IP55. This level rating ensures it is protected from environmental water and dust. Both water and or dust could be harmful to the motor and is often found in the industrial setting. The shaft of the module is not included in the protection area.
Yaskawa manufactured the Sigma II servo motor module line with noise interference in mind. This item reduces noise by using the IGBT power element.
The Yaskawa Sigma II series of motors are manufactured to work with several applications. Some of these applications include PCB drilling machines, robots, conveyors, and packaging systems. Its design is for use indoors, making sure the indoor space is free of corrosive or explosive gasses. It should be installed in a well-ventilated environment, preferably one that is free of dust and moisture. When installing the servo motor, allow space for inspection and cleaning for continued optimal performance.
The servo motor module SGMAH-08AAF41 can be oriented both horizontally and vertically. Before coupling the shafts, be sure to align the shaft of the servomotor with the shaft of the equipment. Be sure to install a protective cover over the servomotor if you foresee exposure to oil or water mist. All cable lines should be free from stress or bends.
The Yaskawa Series II drive module SGMAH-08AAF41 weighs 8lbs and comes with a 2-year warranty.
1. What is the Yaskawa SGMAH-08AAF41 AC Motor used for?
The Yaskawa SGMAH-08AAF41 is a highly efficient AC servo motor, typically used in industrial automation applications that require precise control of motion. Its common applications include robotics, packaging, material handling, and machine tools where high-speed and accurate positioning are critical.
2. What are the power specifications of the SGMAH-08AAF41?
This AC motor has a power rating of 0.75 kilowatts (kW) and operates at a voltage of 200 VAC. It provides a rated speed of 3,000 RPM, with a maximum achievable speed of 5,000 RPM.
3. What is the constant and peak torque provided by the SGMAH-08AAF41 motor?
The Yaskawa SGMAH-08AAF41 provides a constant torque of 2.39 Nm, which is ideal for maintaining continuous operation under load. It also delivers a peak torque of 7.1 Nm, allowing the motor to handle sudden increases in load during brief periods.
4. What kind of encoder does the SGMAH-08AAF41 use?
This motor is equipped with an incremental encoder, providing 13-bit resolution. The encoder plays a crucial role in monitoring the motor’s position and speed, ensuring precise control and feedback for high-accuracy applications.
5. What is the IP rating of the SGMAH-08AAF41 motor?
The Yaskawa SGMAH-08AAF41 has an IP55 rating, which means it is protected against dust ingress and low-pressure water jets from any direction. This makes the motor suitable for use in environments where there may be exposure to dust and moisture, ensuring reliable operation.
6. What type of mounting does the SGMAH-08AAF41 motor support?
The SGMAH-08AAF41 features a flange mounting type, which provides secure and stable attachment in industrial machines. Flange mounting is commonly used in applications where accurate alignment and stable motor positioning are required.
7. Is free shipping available for the SGMAH-08AAF41?
Yes, MRO Electric and Supply offers free shipping for the Yaskawa SGMAH-08AAF41, adding value and convenience for customers purchasing this motor.
8. What is the warranty coverage for the SGMAH-08AAF41 motor?
This Yaskawa AC motor comes with a 2-year warranty from MRO Electric and Supply, ensuring protection against defects and providing customer support in case of any issues during operation.
9. How does the 13-bit encoder resolution benefit the motor's performance?
The 13-bit resolution of the incremental encoder allows the motor to achieve precise control over positioning and speed. This level of resolution ensures smooth and accurate movement, making the SGMAH-08AAF41 ideal for applications requiring high precision.
10. What makes the Yaskawa SGMAH-08AAF41 suitable for industrial automation?
With its high-speed performance (up to 5,000 RPM), robust torque output (2.39 Nm constant and 7.1 Nm peak), and precise encoder feedback, the SGMAH-08AAF41 is designed to excel in demanding industrial environments. The motor's IP55 rating also adds protection in harsh conditions, making it a reliable choice for automation tasks.
