HMIGTO5310

2-year Warranty

Same Day Shipping

Schneider Electric HMIGTO5310

MODICON MAGELIS TOUCHSCREEN PANEL 640 X 480 PIXELS VGA- 10.4 TFT - 96 MB

5/5
5 ratings

Select Condition

Refurbished

4 in stock

New

14 in stock

$2,875.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberHMIGTO5310
ManufacturerSchneider Electric
TypeHMIs
Warranty2 Year
Product weight1.2 kg
Range of productMagelis GTO
Product or component typeAdvanced touchscreen panel
Display colour65536 colours
Display size10.4 inch
SupplyExternal source
Operating systemMagelis
Battery typeLithium battery for internal RAM, autonomy: 100 days, charging time = 5 d, battery life = 10 yr
Terminal typeTouchscreen display
Display typeBacklit colour TFT LCD
Display resolution640 x 480 pixels VGA
Touch sensitive zone1024 x 1024
Touch panelResistive film, 1000000 cycles
Backlight lifespan50000 hours (white) at 25 °C
Brightness16 levels - control by touch panel
16 levels - control by software
Character fontASCII
[Us] rated supply voltage24 V DC
Supply voltage limits19.2...28.8 V
Inrush current<= 30 A
Power consumption in W<= 17 W
<= 12 W (when power is not supplied to external devices)
<= 7 W (when backlight is OFF)
<= 8 W (when backlight is dimmed)
Local signallingStatus LED (orange) flashing software starting up
Status LED (green) steady offline
Status LED (green) steady operating
Status LED (red) steady power supply (ON)
Status LED (clear) faded power supply (OFF)
COM2 LED (yellow) steady data is being transmitted
COM2 LED (yellow) faded no data transmission
SD card LED (green) steady card is inserted
SD card LED (green) faded card is not inserted or is not being accessed
Software designationVijeo Designer configuration software >= V6.1
Memory description96 MB flash (EPROM)
Data backed up512 kB internal RAM (SRAM)
Data storage equipmentSD card <= 32 GB
SDHC card <= 32 GB
Downloadable protocolsModbus Plus Schneider Electric Modicon
FIPWAY Schneider Electric Modicon
Modbus TCP Schneider Electric Modicon
Modbus Schneider Electric Modicon
Third party protocols Mitsubishi Melsec
Third party protocols Omron Sysmac
Third party protocols Rockwell Automation Allen-Bradley
Third party protocols Siemens Simatic
Uni-TE Schneider Electric Modicon
Integrated connection typeCOM1 serial link SUB-D 9, interface: RS232C, transmission rate: 2400...115200 bps
COM2 serial link RJ45, interface: RS485, transmission rate: 2400...115200 bps
COM2 serial link RJ45, interface: RS485, transmission rate: 187.5 kbps compatible with Siemens
MPI
Ethernet RJ45, interface: 10BASE-T/100BASE-TX
Ethernet RJ45, interface: IEEE 802.3
USB 2.0 type A
USB 2.0 type mini B
Product mountingFlush mounting
Fixing modeBy 4 screw clamps
Front materialPPT
Enclosure materialPPT
Type of coolingNatural convection
Width272.5 mm
Height214.5 mm
Depth57 mm

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed HMIGTO5310 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this HMIGTO5310 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty HMIGTO5310, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 3lbs

Want it shipped today?

  • Order within the next 11 hours and 48 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty HMIGTO5310 for credit when ordering from MRO Electric

What replaces the Magelis XBTG5330 HMI?

  • The repalcement is the XBTGT5330. However the Magelis XBTGT5330 HMI is no longer produces and was replaced by the HMIGTO5310.

Is the Magelis HMIGTO series ATEX Certified?

  • Yes, the Magelis HMIGTO is ATEX certified.
MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric HMIGTO5310 Overview

Schneider Electric HMIGTO5310: Advanced Touchscreen Panel for Industrial Applications

The Schneider Electric HMIGTO5310 is a high-performance Human-Machine Interface (HMI) designed for industrial automation and control applications. As part of the Magelis GTO range, this advanced touchscreen panel offers exceptional reliability, durability, and functionality, making it an ideal solution for various industrial environments.

High-Resolution Display and Touchscreen Functionality

Equipped with a 10.4-inch backlit color TFT LCD, the HMIGTO5310 delivers a bright and clear display with a resolution of 640 x 480 pixels (VGA). It supports 65,536 colors, ensuring a detailed and vibrant visual representation of process data and user interfaces. The resistive film touchscreen provides high precision, featuring a touch-sensitive zone of 1024 x 1024 and a lifespan of up to 1,000,000 cycles, making it highly durable for long-term use. The display's brightness can be adjusted across 16 levels through the software or touch panel, offering adaptability to different lighting conditions.

Reliable Power Supply and Energy Efficiency

The HMIGTO5310 operates on a rated supply voltage of 24V DC, with a voltage tolerance range of 19.2V to 28.8V. Its power consumption is optimized to ensure efficiency, consuming up to 17W under full operation. Lower power modes are available, including 12W when external devices are not powered, 8W in dimmed backlight mode, and 7W when the backlight is completely off. This energy-efficient design helps reduce operational costs and extend the device's life.

Comprehensive Communication and Connectivity Options

Designed to integrate seamlessly into industrial networks, the HMIGTO5310 has multiple communication interfaces. It features a COM1 serial link (RS232C) with a SUB-D 9 connection, a COM2 serial link (RS485) with an RJ45 connection, and an additional RS485 interface compatible with Siemens MPI. The device supports Ethernet (RJ45) for high-speed data transmission with 10BASE-T/100BASE-TX connectivity and two USB ports (one Type A and one Mini B) for added functionality. This extensive range of communication options enables connectivity with various industrial controllers and third-party devices.

Data Storage and Software Compatibility

The HMIGTO5310 offers substantial memory capacity, featuring 96MB of flash memory (EPROM) and 512kB of internal RAM (SRAM) for data backup. It also supports SD and SDHC cards up to 32GB for additional storage. The device is fully compatible with Schneider Electric's Vijeo Designer configuration software (version 6.1 or later), allowing intuitive programming and easy integration into industrial automation systems.

User-Friendly Design and Operational Status Indicators

The HMIGTO5310 includes several LED indicators for enhanced usability to provide real-time status feedback. The status LEDs indicate power supply conditions, software startup progress, and operational states, while additional LEDs for COM2 and SD card slots display communication and storage activity. This intuitive signaling system lets operators quickly diagnose and troubleshoot potential issues.

Rugged Build and Easy Installation

Constructed with a robust PPT front and enclosure material, the HMIGTO5310 is designed to withstand harsh industrial conditions. It is mounted flush and secured using four screw clamps, ensuring a stable and secure installation. Natural convection cooling eliminates additional cooling mechanisms, reducing maintenance requirements. The device's compact dimensions (272.5 mm width, 214.5 mm height, and 57 mm depth) allow it to fit easily into control panels and other industrial setups.

Warranty and Availability

MRO Electric and Supply offers the Schneider Electric HMIGTO5310 a two-year warranty and free shipping. This ensures customers receive a high-quality, reliable product with excellent after-sales support. The unit is available immediately, making it a convenient and efficient solution for businesses looking to enhance their automation capabilities.

Frequently Asked Questions (FAQs)

What is the primary application of the HMIGTO5310?

The HMIGTO5310 is primarily used as a Human-Machine Interface (HMI) for industrial automation, providing operators with real-time control and monitoring of processes.

What type of touchscreen does the HMIGTO5310 use?

It features a resistive film touchscreen with a resolution of 1024 x 1024, offering precise touch recognition and long-term durability.

Does the HMIGTO5310 support Ethernet connectivity?

It includes an Ethernet RJ45 port supporting 10BASE-T/100BASE-TX for fast network communication.

What communication protocols are compatible with this device?

It supports multiple protocols, including Modbus, Modbus TCP, Siemens Simatic, Rockwell Allen-Bradley, Mitsubishi Melsec, and Omron Sysmac, making it highly versatile.

How is the HMIGTO5310 mounted?

It is designed for flush mounting and is secured using four screw clamps for a stable installation.

What is the lifespan of the backlight?

The backlight lifespan is approximately 50,000 hours at 25°C, ensuring long-term usability.

Can external storage be added to the device?

The HMIGTO5310 supports SD and SDHC cards up to 32GB for extended data storage.

What are the power requirements for this device?

It operates on a 24V DC power supply, and depending on usage, its power consumption ranges from 7W to 17W.

What software is used to configure the HMIGTO5310?

It is configured using Schneider Electric's Vijeo Designer software, version 6.1 or later.

Is the HMIGTO5310 available for immediate purchase?

MRO Electric and Supply has the HMIGTO5310 in stock and offers immediate shipping with a two-year warranty.
