The Schneider Electric HMIGTO4310 is an advanced touchscreen panel designed to usher in a new era of human-machine interaction. As part of the Magelis GTO series, this HMI (Human-Machine Interface) device stands out with its cutting-edge features, ergonomic design, and robust capabilities.

Features and Specifications:

Visual Excellence:

The HMIGTO4310 boasts a 7.5-inch display with a vibrant palette of 65536 colors, providing clear and detailed visuals. The backlit color TFT LCD ensures a crisp and dynamic viewing experience, making it suitable for applications where visual precision is paramount.

Responsive Touch Interface:

Equipped with a resistive film touch panel, the device offers a touch-sensitive zone of 1024 x 1024, providing a highly responsive and intuitive interface. The touchscreen display allows users to interact effortlessly, facilitating seamless navigation and control.

Long-lasting Performance:

With a display resolution of 640 x 480 pixels (VGA), the HMIGTO4310 delivers sharp and detailed graphics. The backlight lifespan of 50000 hours (white) ensures longevity, making it suitable for continuous operation in industrial environments.

Power Efficiency:

Designed for energy efficiency, the HMI operates on a rated supply voltage of 24 V DC, with supply voltage limits ranging from 19.2 to 28.8 V. The power consumption is optimized, with varying levels: <= 12 W in standard operation, <= 8 W when power is not supplied to external devices, <= 5 W when the backlight is off, and <= 5.5 W when the backlight is dimmed.

Status Indicators:

The device incorporates a range of status LEDs providing visual cues. The LEDs include status indicators for software startup, offline/online operation, power supply status, data transmission, and SD card access. These indicators enhance user awareness and contribute to efficient diagnostics.

Versatile Connectivity:

The HMIGTO4310 offers a diverse range of integrated connection options, including COM1 and COM2 serial links, Ethernet interfaces, and USB ports. These connections support protocols such as Modbus Plus, FIPWAY, Modbus TCP, and third-party protocols like Mitsubishi Melsec, Omron Sysmac, Rockwell Automation Allen-Bradley, and Siemens Simatic.

Storage and Memory Capacity:

With 96 MB of flash (EPROM) memory and 512 kB of internal RAM (SRAM), the HMI ensures sufficient storage for applications. Data can be backed up, and additional storage is facilitated through SD cards with a capacity of up to 32 GB.

Compact Design for Easy Integration:

Measuring 218 mm in width, 173 mm in height, and 60 mm in depth, the HMIGTO4310 features a flush-mounting design with four screw clamps for secure fixing. The front and enclosure materials are made of PPT (Polypropylene Terephthalate), ensuring durability in challenging industrial environments.

Efficient Cooling and Material Composition:

The HMI utilizes natural convection for cooling, eliminating the need for external cooling systems. The materials used, both in the front and enclosure, are PPT, contributing to the device's robustness and reliability.

FAQ

Q1: What is the Schneider Electric HMIGTO4310, and how does it stand out in the realm of HMIs?

A1: The HMIGTO4310 is an advanced touchscreen panel manufactured by Schneider Electric, specifically part of the Magelis GTO series. It stands out with its 7.5-inch display, responsive touch interface, and versatile connectivity options, making it an exemplary HMI solution.

Q2: What is the display size and resolution of the HMIGTO4310?

A2: The device features a 7.5-inch display with a resolution of 640 x 480 pixels (VGA), providing clear and detailed visuals for enhanced user experience.

Q3: How is the touch interface of the HMIGTO4310 designed, and what is its touch panel type?

A3: The device incorporates a resistive film touch panel, offering a touch-sensitive zone of 1024 x 1024 and providing users with a highly responsive and intuitive interface for seamless navigation.

Q4: What are the power consumption and voltage specifications of the HMIGTO4310?

A4: The HMI operates on a rated supply voltage of 24 V DC, with power consumption levels optimized for energy efficiency. The power consumption ranges from <= 12 W during standard operation to <= 5 W when the backlight is off.

Q5: How long is the battery autonomy, and what is the charging time for the internal RAM battery?

A5: The HMIGTO4310 is equipped with a lithium battery for internal RAM with an autonomy of 100 days. The charging time for this battery is 5 days, and its overall lifespan is approximately 10 years.

Q6: What are the local signaling indicators on the HMIGTO4310, and how do they assist in operation?

A6: The device incorporates various status LEDs, including indicators for software startup, offline/online operation, power supply status, data transmission, and SD card access. These LEDs provide visual cues for efficient diagnostics and user awareness.

Q7: What types of connections does the HMIGTO4310 support, and which protocols are compatible?

A7: The HMI offers diverse connectivity options, including COM1 and COM2 serial links, Ethernet interfaces, and USB ports. It supports protocols such as Modbus Plus, FIPWAY, Modbus TCP, and third-party protocols like Mitsubishi Melsec, Omron Sysmac, Rockwell Automation Allen-Bradley, and Siemens Simatic.

Q8: Can the HMIGTO4310 store data, and what is the available memory capacity?

A8: Yes, the device has 96 MB of flash (EPROM) memory for storing data, and data can be backed up with 512 kB of internal RAM (SRAM). Additional storage is supported through SD cards with a capacity of up to 32 GB.

Q9: What are the dimensions and materials used in the construction of the HMIGTO4310?

A9: The HMI has dimensions of 218 mm (width) x 173 mm (height) x 60 mm (depth) and features a flush-mounting design with four screw clamps. The front and enclosure materials are made of Polypropylene Terephthalate (PPT), contributing to the device's durability.

Q10: How does the HMIGTO4310 achieve cooling, and what is its material composition?

A10: The HMI achieves cooling through natural convection, eliminating the need for external cooling systems. Both the front and enclosure materials are composed of Polypropylene Terephthalate (PPT), ensuring robustness and reliability in industrial environments.
