I/O MODULES DIGITAL 32 INPUT VDC I/O MODULE
5 in stock
Ships Today
Free Shipping
2 Year warranty
| Part Number | BMXDDI3202K |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | BMX-DDI-3202K |
| Warranty | 2 Year |
| Range | Modicon X80 |
| Category | Discrete input |
| Sensor power supply | 19...30 V |
| MTBF reliability | 696320 H |
| Input | 32 Discrete in |
| Discrete input | Isolated |
| Discrete input current | 2.5 mA |
| Power dissipation in W | <= 3.9 W |
| Status LED | 1 LED red module error (ERR) 1 LED green module operating (RUN) 1 LED per channel green channel diagnostic 1 LED red module I/O |
| Paralleling of inputs | No |
| Current state 0 guaranteed | <= 1.5 mA |
| Voltage state 1 guaranteed | >= 11 V |
| Current state 1 guaranteed | >= 2 mA |
| Voltage state 0 guaranteed | <= 5 V |
| Discrete input voltage | 24 V DC positive |
| Input compatibility | Input compatibility With 2-wire/3-wire proximity sensors conforming to IEC 60947-5-2 |
| Input type | Current sink |
| Typical current consumption | 140 mA at 3.3 V DC |
| Insulation resistance | > 10 MOhm 500 V DC |
| DC maximum filtering time | 7 ms |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed BMXDDI3202K to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this BMXDDI3202K we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty BMXDDI3202K, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty BMXDDI3202K for credit when ordering from MRO Electric
The Schneider Electric BMXDDI3202K is within the Modicon X80 product range in industrial automation and control systems. It is engineered to meet the demands of diverse industrial automation and control applications. It excels in delivering high-performance capabilities for discrete input functions, catering to a wide spectrum of systems and processes.
As part of the Modicon X80 series, the BMXDDI3202K stands as a discrete input, equipped with 32 discrete input channels. These inputs are isolated, offering robust performance and reliability in industrial settings. The module operates on a 24 V DC voltage supply, with a discrete input logic that is positive. Each discrete input channel handles a current of 2.5 mA.
The BMXDDI3202K is designed with compatibility in mind, readily accommodating 2-wire and 3-wire proximity sensors that adhere to IEC 60947-5-2 and IEC 61131-2 Type 1 standards. It accepts sensor power supply voltages within the range of 19 to 30 V, ensuring flexibility in sensor integration.
The module maintains stringent logic levels, guaranteeing a current of 2 mA or higher for logic level 1 and equal to or less than 0.5 mA for logic level 0. Its input impedance measures 9600 Ohms, contributing to its precision in input signal processing. It offers enhanced safety with insulation resistance surpassing 10 MOhms at 500 V DC.
The BMXDDI3202K boasts a power dissipation of 3.9 W and exhibits an impressive DC response time of 4 ms (with a maximum of 7 ms). It does not allow input paralleling, ensuring precise data handling. The module consumes 121 mA at 3.3 V DC and demonstrates outstanding reliability with a Mean Time Between Failures (MTBF) rating of 905,000 hours.
Protection features are integral to its design, incorporating external fuses per group of channels rated at 0.5 A fast blow, as well as reverse polarity protection. The module detects sensor faults at voltages below 14 V DC and signals sensor functionality at voltages exceeding 18 V DC. Status LEDs provide essential feedback, including a green LED for module operating status (RUN), green LEDs for channel diagnostics, and two red LEDs for module errors (ERR) and module I/O.
In terms of environmental robustness, the BMXDDI3202K excels with an IP20 degree of protection, safeguarding against solid objects and dust. It aligns with the 2014/35/EU low voltage directive and the 2014/30/EU electromagnetic compatibility directive.
With a dielectric strength of 1500 V AC at 50/60 Hz for 1 minute between primary and secondary circuits, and a capability to withstand 500 V DC for 1 minute between groups of channels, the module ensures electrical integrity. It remains resilient against vibrations up to 3 gn and can endure shocks up to 30 gn.
Operational versatility is evident in its temperature range, operating from 0°C to 60°C, and it can be stored in conditions ranging from -40°C to 85°C. The module functions seamlessly in relative humidity conditions spanning from 5% to 95% at 55°C, without the risk of condensation. It is suitable for operation at altitudes up to 2000 meters, and for altitudes exceeding 2000 meters, derating factors should be considered, up to a maximum altitude of 5000 meters.
What is the model number of this Schneider Electric I/O module?
The model number is BMX-DDI-3202K, part of the Modicon X80 range.
What type of I/O module is the BMX-DDI-3202K?
The BMX-DDI-3202K is a Discrete Input module designed for automation systems.
What is the warranty period for this module?
This I/O module comes with a 2-year MRO Electric and Supply warranty, ensuring reliability and customer satisfaction.
What is the sensor power supply range for this module?
The sensor power supply range is 19 to 30 V, making it suitable for various input applications.
How many discrete inputs does the BMX-DDI-3202K support?
This module supports 32 discrete inputs, allowing for multiple sensor connections in a single module.
Is the discrete input of the module isolated?
Yes, the BMX-DDI-3202 K's discrete inputs are isolated, providing better noise immunity and protection for the system.
What is the typical current consumption for this module?
The typical current consumption for the BMX-DDI-3202K is 140 mA at 3.3 V DC.
What are the current and voltage guarantees for state 0 and state 1?
For state 0, the current is guaranteed to be ≤ 1.5 mA and the voltage is guaranteed to be ≤ 5 V. For state 1, the current is guaranteed to be ≥ two mA and the voltage is guaranteed to be ≥ 11 V.
What is the insulation resistance for the BMX-DDI-3202K?
The insulation resistance is more excellent than 10 MΩ at 500 V DC, ensuring robust electrical performance and safety.
Does the module have any status LEDs?
Yes, the module features several status LEDs:
What is this module's MTBF (Mean Time Between Failures) reliability?
The BMX-DDI-3202 K's MTBF reliability is 696,320 hours, indicating a high level of reliability for long-term operations.
What types of sensors are compatible with this module?
The BMX-DDI-3202K is compatible with 2-wire and 3-wire proximity sensors that conform to IEC 60947-5-2 standards, making it versatile for various applications.
What is the maximum DC filtering time for this module?
The maximum DC filtering time for the BMX-DDI-3202K is 7 ms, allowing for effective signal processing.
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like BMXDDI3202K, take a look at more from our I/O Modules line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our BMXDDI3202K products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
