ATV630 VARIABLE SPEED DRIVE 75 KW 100 HP 380 TO 480 VOLT IP21
| Part Number | ATV630D75N4 |
| Manufacturer | Schneider Electric |
| Type | AC Drives |
| Warranty | 2 Year |
| Range | ATV600 |
| Component | Variable speed drive |
| Application | Process and utilities |
| Varient | Standard |
| Nominal switching frequency | 2.5 kHz |
| Destination | Asynchronous motors Synchronous motors |
| EMC filter | Integrated 492.13 f |
| Protection | IP21IEC 61800-5-1 IP21IEC 60529 |
| Rated voltage | 380...480 V |
| Protection | UL type 1 UL 508C |
| Safety function | STO (safe torque off) SIL 3 |
| Cooling | Forced convection |
| Supply frequency | 50...60 Hz - 5...5 % 380...480 V - 15...10 % |
| Motor power | 75 kW normal duty) 55 kW heavy duty) |
| Max hp | 100 hp normal duty 75 hp heavy duty |
| Prospective line Isc | 50 kA |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed ATV630D75N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this ATV630D75N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty ATV630D75N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty ATV630D75N4 for credit when ordering from MRO Electric
The Altivar ATV630D75N4 is a variable speed drive (VSD) manufactured by Schneider Electric, specifically designed for process and utility applications. With a power rating of 75 kW/100 hp and a supply voltage range of 380-480 V, this VSD is capable of controlling both asynchronous and synchronous motors, providing efficient and precise motor control in various industrial settings. These products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
One notable feature of the Altivar ATV630D75N4 is its integrated EMC filter, which ensures compliance with EN/IEC 61800-3 category C3 standards for electromagnetic compatibility. This filter reduces electromagnetic interference, minimizing the impact on other equipment and improving overall system performance. The VSD is also rated with an IP21 degree of protection according to IEC 61800-5-1 and IEC 60529, providing adequate protection against solid objects and limited protection against moisture.
The VSD operates at a frequency range of 0.1 to 500 Hz, allowing for flexible speed control of the connected motor. The nominal switching frequency is 2.5 kHz, but it can be adjusted between 2 and 8 kHz with derating. This flexibility enables users to optimize the drive's performance based on their specific application requirements.
In terms of safety, the Altivar ATV630D75N4 is equipped with a Safe Torque Off (STO) function certified at Safety Integrity Level 3 (SIL 3). This function ensures the motor's torque is safely disconnected during potentially hazardous situations, providing an extra layer of protection for personnel and equipment.
The VSD offers multiple communication options, including Ethernet, Modbus serial, and Modbus TCP protocols, enabling seamless integration with industrial automation systems. It also features expansion slots for additional communication modules, such as Profibus DP V1, PROFINET, DeviceNet, and more.
Installation and configuration of the Altivar ATV630D75N4 are made easier with its user-friendly interface and diagnostic LEDs. The VSD supports various control profiles for both asynchronous and synchronous motors, including variable torque, constant torque, and optimized torque modes. It also provides features like motor slip compensation and adjustable acceleration and deceleration ramps, allowing for precise motor control and smooth operation.
To ensure the longevity of the VSD and connected equipment, the Altivar ATV630D75N4 incorporates multiple protection functions. These include thermal protection for the motor and the drive, safe torque off for the motor and drive, overcurrent and overload protection, short-circuit protection, and various other safeguards against voltage fluctuations, phase loss, overvoltage, and more.
The VSD can be mounted on a wall and is designed for vertical operation with a maximum tilt angle of +/- 10 degrees. It complies with various international standards, such as UL 508C, EN/IEC 61800-3, EN/IEC 61800-5-1, IEC 61000-3-12, and IEC 60721-3.
What is the application range of the ATV630D75N4 AC Drive?
It is designed for process and utilities applications.
What types of motors are compatible with this drive?
Both asynchronous and synchronous motors are compatible.
Does it come with an EMC filter?
Yes, it comes with an integrated EMC filter.
What are the primary protection ratings for this drive?
It is rated IP21 according to both IEC 61800-5-1 and IEC 60529 standards. Additionally, it has UL Type 1 and UL 508C protection.
What safety functions does it offer?
It offers STO (Safe Torque Off) with SIL 3 safety level.
How is the cooling managed in this drive?
Cooling is achieved through forced convection.
What is the range of supply frequency and voltage?
The supply frequency ranges from 50 to 60 Hz with a variation of ±5%, and the voltage ranges from 380 to 480 V with a variation of ±15% for frequency and ±10% for voltage.
What are the power ratings for standard and heavy-duty operations?
It has a motor power of 75 kW for regular duty and 55 kW for heavy duty.
What is the maximum horsepower supported by this drive?
It supports up to 100 hp for regular and 75 hp for heavy duty.
What is the prospective line ISC (Short Circuit Current)?
The prospective line ISC is 50 kA.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like ATV630D75N4, take a look at more from our AC Drives line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our ATV630D75N4 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
