1 Available
2 Year warranty
| Part Number | ATV31HD15N4 |
| Manufacturer | Schneider Electric |
| Type | AC Drives |
| Warranty | 2 Year |
| Range | Altivar |
| Category | ATV31 |
| Description | Variable speed drive |
| EMC Filter | Integrated |
| Voltage | 380...500 V - 5...5 % |
| Motor power | 15 kW 4 kHz |
| Application | Simple machine |
| Line current | 36.8 A 500 V 48.2 A 380 V, Isc = 1 kA |
| Prospective line Isc | 1 kA |
| Assembly | With heat sink |
| Frequency | 50...60 Hz - 5...5 % |
| Apparent power | 32 kVA |
| Maximum transient current | 49.5 A 60 s |
| Analog input | 3 |
| Analog output | 2 |
| Destination | Asynchronous motors |
| Frequency | 47.5...63 Hz |
| Switching frequency | 2...16 kHz adjustable |
| Speed | 1…50 |
| Discrete input | 6 |
| Discrete output | 2 |
| Connector | 1 RJ45 CANopen via VW3 CANTAP2 adaptor 1 RJ45 Modbus |
| Interface | RS485 multidrop serial link CANopen via VW3 CANTAP2 adaptor RS485 multidrop serial link Modbus |
| Marking | CE |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed ATV31HD15N4 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this ATV31HD15N4 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty ATV31HD15N4, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty ATV31HD15N4 for credit when ordering from MRO Electric
The Schneider Electric ATV31HD15N4 Variable Speed Drive represents a pinnacle of efficiency and reliability in industrial motor control. Designed to offer precise control and optimized performance, this drive is tailored to meet the demands of modern automation systems.
Equipped with a 15 kW motor power and compatible with a 500V 3-phase supply, the ATV31HD15N4 drive ensures robust motor control for a wide range of industrial applications. Its integrated EMC filter and IP20 protection make it suitable for diverse environments.
The ATV31HD15N4 drive is part of the Altivar range and is a versatile variable-speed drive. Its simple machine-specific application offers flexibility in configuration and operation, making it ideal for various industrial settings.
The ATV31HD15N4 drive delivers precise control over motor speed and torque by utilizing sensorless flux vector control with PWM-type motor control signals. Its factory-set constant torque mode ensures consistent performance across different load conditions.
Featuring multiple analog and discrete inputs and outputs, the ATV31HD15N4 drive offers extensive connectivity options for seamless integration into automation systems. Its analog input types include configurable voltage and current inputs, ensuring compatibility with various sensors and control devices.
With a nominal output current of 33 A at 4 kHz and a maximum transient current of 49.5 A for 60 seconds, the ATV31HD15N4 drive optimizes power consumption while maintaining reliable operation. Its energy-efficient design minimizes operational costs and environmental impact.
Built to withstand harsh industrial environments, the ATV31HD15N4 drive features sturdy construction and protective treatment. It is resistant to vibrations, shocks, and temperature variations, ensuring reliable performance in demanding conditions.
Equipped with RS485 multidrop serial link interfaces for CANopen and Modbus communication protocols, the ATV31HD15N4 drive enables seamless connectivity with other control devices and systems. Its transmission rates and addressing options ensure efficient data exchange and system integration.
The ATV31HD15N4 drive measures 595 x 234 x 268 mm and weighs 24.25 lbs (11 kg). Its compact design saves space in control cabinets. Its easy-to-use connectors and intuitive interface facilitate quick and hassle-free installation.
Q: What is the Schneider Electric ATV31HD15N4 Variable Speed Drive? A: The ATV31HD15N4 is a variable-speed drive designed for industrial motor control applications, offering precise speed and torque control for motors in diverse industrial settings.
Q: What are the key features of the ATV31HD15N4 drive? A: The ATV31HD15N4 drive features a 15 kW motor power, compatibility with 500V 3-phase supply, integrated EMC filter, IP20 protection, advanced motor control profiles, comprehensive connectivity options, efficient power management, and robust construction for durability.
Q: What motor control profiles does the ATV31HD15N4 drive support? A: The drive supports sensorless flux vector control with PWM-type motor control signals and offers a factory-set constant torque mode for consistent performance across different load conditions.
Q: What communication protocols does the ATV31HD15N4 drive support?
A: The drive has RS485 multidrop serial link interfaces for CANopen and Modbus communication protocols, enabling seamless connectivity with other control devices and systems.
Q: What are the environmental specifications of the ATV31HD15N4 drive?
A: The drive is built to withstand harsh industrial environments, offering resistance against vibrations, shocks, temperature variations, and humidity. It features protective treatment and complies with relevant standards for durability and reliability.
Q: How does the ATV31HD15N4 drive contribute to energy efficiency? A: The drive optimizes power consumption while maintaining reliable operation, minimizing operational costs and environmental impact. Its efficient power management ensures optimal performance and energy savings.
Q: Is the ATV31HD15N4 drive easy to install?
A: The drive features a compact design and intuitive interface, facilitating quick and hassle-free installation. Its connectors are easy to use and save space in control cabinets.
Q: What applications is the ATV31HD15N4 drive suitable for?
A: The drive is suitable for various industrial motor control applications, including pumps, fans, conveyors, compressors, and more. It offers precise speed and torque control for enhanced productivity and efficiency.
Q: Does the ATV31HD15N4 drive come with any certifications?
A: Yes, the drive is CE-certified and complies with relevant industry standards, ensuring quality, safety, and reliability in industrial automation systems.
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
