ALTIVAR 312 VARIABLE SPEED DRIVE, 5.5KW - 12.8KVA - 292W - 200..240V- 3-PHASE SUPPLY
| Part Number | ATV312HU55M3 |
| Manufacturer | Schneider Electric |
| Type | AC Drives |
| Warranty | 2 Year |
| Range | ATV312 |
| Component | Variabel speed drive |
| Application | Simple machine |
| Motor power | 5.5 kW |
| Destination | Asynchronous motors |
| Hp motor power | 7.5 hp |
| Phase | 3-Phase |
| Supply Voltage | 200...240 V (- 15...10 %) |
| Assembly | with Heat sink |
| Line current | 32 Afor 240 V 36.8 Afor 200 V, 22 kA |
| EMC filter | No |
| Speed range | 1…50 |
| Power dissipation | 292 W at nominal load |
| Apparent power | 12.8 kVA |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed ATV312HU55M3 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this ATV312HU55M3 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty ATV312HU55M3, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty ATV312HU55M3 for credit when ordering from MRO Electric
The Schneider Electric ATV312HU55M3 is an AC drive that provides reliable and efficient motor control for various simple machine applications. This drive belongs to Schneider Electric’s ATV312 series, known for its versatility and user-friendly operation. It is built to control the speed and torque of asynchronous motors, making it ideal for a wide range of industrial and commercial uses. With a power rating of 5.5 kW (equivalent to 7.5 hp), it can effectively drive motors in light to medium-duty applications.
The ATV312HU55M3 operates on a three-phase power supply with a voltage range of 200 to 240 V. It can handle fluctuations within a tolerance of -15% to +10%, ensuring stability and consistent performance in different power conditions. This flexibility in voltage makes it suitable for global installations where supply conditions may vary. The drive’s line current is rated at 32 A for 240 V and 36.8 A for 200 V, demonstrating its ability to handle substantial loads while maintaining energy efficiency.
The ATV312HU55M3 is equipped with a heat sink assembly to maintain optimal operating temperatures and ensure reliability. This feature helps dissipate the 292 W of power dissipation at a nominal load, preventing overheating and prolonging the drive's life. The drive supports a wide speed range of 1 to 50, providing precise and flexible control over motor speeds. This capability makes it particularly effective in applications requiring varying motor speeds to achieve different operational requirements.
As a variable-speed drive, the ATV312HU55M3 is designed with simplicity and efficiency in mind. Its compact and robust design makes it easy to integrate into existing control panels or enclosures. Although the drive does not include an EMC filter, it can still deliver reliable performance in standard environments without electromagnetic disturbances. However, an external filter may be necessary for applications with strict electromagnetic compatibility requirements to meet specific regulations.
With a rated apparent power of 12.8 kVA, the ATV312HU55M3 can effectively drive medium-sized motors and handle moderate workloads. It provides sufficient capacity to power various simple machines in automation, material handling, and light industrial processes. Additionally, the drive offers a short-circuit current rating of 22 kA, providing robust protection in the event of electrical faults.
Schneider Electric offers a 2-year warranty on the ATV312HU55M3 through MRO Electric and Supply. This warranty demonstrates Schneider Electric’s commitment to quality and customer satisfaction, ensuring that customers can trust the durability and longevity of their investment.
1. What type of motors is the ATV312HU55M3 suitable for?
The ATV312HU55M3 is designed to control asynchronous motors in simple machine applications. It effectively manages motor speed and torque, making it ideal for small to medium-sized machinery in industrial and commercial settings.
2. What kind of applications is this AC drive suitable for?
This AC drive controls simple machines, such as conveyors, pumps, fans, and material handling equipment. Its user-friendly design and versatile speed control make straightforward motor management applications practical.
3. Does the ATV312HU55M3 have an EMC filter?
No, the ATV312HU55M3 does not include an internal EMC filter. However, for applications that require electromagnetic compatibility, an external EMC filter may be necessary to meet the required standards.
4. What is the speed range of the ATV312HU55M3?
The drive features a speed range of 1 to 50, allowing for precise and flexible control of motor speeds. This wide range enables the drive to adapt to different operational requirements in various applications.
5. How does the heat sink assembly benefit the ATV312HU55M3?
The heat sink assembly in the ATV312HU55M3 helps efficiently dissipate the 292 W of power dissipation at a nominal load, preventing overheating and enhancing the overall reliability and lifespan of the drive.
6. Is there a warranty for the ATV312HU55M3?
Yes, the ATV312HU55M3 comes with a 2-year warranty from MRO Electric and Supply, providing customers with peace of mind regarding the drive's quality and long-term performance.
7. What is the input voltage range for the ATV312HU55M3?
The input voltage range for the ATV312HU55M3 is 200 to 240 V, with a tolerance of -15% to +10%. This range allows the drive to operate efficiently across various global power supply conditions.
