Schneider Electric ATV312HD11M3

ATV312 Variable Speed Drive

The ATV312 variable speed drive is a sophisticated solution designed for controlling asynchronous motors in simple machines, offering a range of features that contribute to its optimal performance.

Powerful and Versatile

With a motor power of 11 kW and a maximum horsepower rating of 15 hp, the ATV312 provides powerful and versatile control over a diverse range of applications.

Adaptable Power Supply

One of its standout features is its adaptability to different power supply conditions. Operating within a supply voltage range of 200 to 240 V and supporting 3-phase input, the ATV312 ensures stable and reliable performance.

Dynamic Motor Control

Incorporating sensorless flux vector control with PWM type motor control signal, the ATV312 delivers precise and dynamic control over asynchronous motors. The factory-set constant torque profile ensures optimal performance in various operating conditions.

Efficient Electrical Connections

The electrical connections are streamlined for easy installation, with terminals like Al1, Al2, Al3, AOV, AOC, R1A, R1B, R1C, R2A, R2B, LI1...LI6 is designed to facilitate a smooth setup process.

Comprehensive Protection Mechanisms

Equipped with advanced protection features, including input phase breaks drive, line supply overvoltage and undervoltage safety circuits, motor phase breaks drive, and overheating protection, the ATV312 ensures the longevity of the drive and connected motor.

Communication Capabilities

The ATV312 boasts communication capabilities with support for Modbus and CANopen protocols, enhancing its integration into industrial automation systems. Additional option cards, including CANopen daisy chain, DeviceNet, Fipio, Modbus TCP, and Profibus DP, expand its connectivity options.

Flexible Parameter Adjustments

The ATV312 offers a wide range of parameter adjustments, allowing users to customize acceleration and deceleration ramps linearly from 0.1 to 999.9 seconds. Customizable braking torque, regulation loop frequency, and motor slip compensation enable fine-tuning for specific application requirements.

Compact and Well-Designed

Physically, the ATV312 is compact and well-designed, with an IP20 to IP41 degree of protection, depending on the part of the unit. This ensures its resilience in various industrial environments.

Certified to International Standards

Certified to meet standards such as IEC 61800-5-1 and IEC 61800-3, the ATV312 has received product certifications, including GOST, C-tick, UL, CSA, DNV, and NOM, attesting to its compliance with international quality and safety standards.

Frequently Asked Questions

• The ATV312 is designed for controlling asynchronous motors in simple machines, offering precise and dynamic motor control.

2. What is the power rating of the ATV312?

• The ATV312 has a motor power of 11 kW with a maximum horsepower rating of 15 hp, making it suitable for a variety of applications.

3. What is the supply voltage range supported by the ATV312?

• The ATV312 operates within a supply voltage range of 200 to 240 V, accommodating different power supply conditions.

4. What protection features does the ATV312 offer?

• The ATV312 is equipped with advanced protection mechanisms, including input phase breaks drive, line supply overvoltage and undervoltage safety circuits, motor phase breaks drive, and overheating protection.

5. Can the ATV312 communicate with other devices in an industrial automation system?

• Yes, the ATV312 has communication capabilities with support for Modbus and CANopen protocols. It also offers additional option cards for enhanced connectivity, such as CANopen daisy chain, DeviceNet, Fipio, Modbus TCP, and Profibus DP.

6. Are the parameter settings customizable on the ATV312?

• Yes, the ATV312 provides a wide range of parameter adjustments, allowing users to customize acceleration and deceleration ramps, braking torque, regulation loop frequency, and motor slip compensation to meet specific application requirements.

7. What environmental conditions is the ATV312 suitable for?

• The ATV312 is designed to operate in a broad range of environmental conditions. It has a wide operating temperature range and is suitable for various industrial environments.

8. What certifications does the ATV312 hold?

• The ATV312 is certified to meet standards such as IEC 61800-5-1 and IEC 61800-3. It holds product certifications including GOST, C-tick, UL, CSA, DNV, and NOM, ensuring compliance with international quality and safety standards.

9. How compact is the ATV312?

• Physically, the ATV312 is compact and well-designed, with dimensions of 330 x 245 x 190 mm, making it suitable for installations with space constraints.

10. Can the ATV312 be used in different industrial automation setups?

• Yes, the ATV312's versatility and flexibility make it suitable for a wide range of industrial automation setups, offering efficient and reliable motor control in various applications.
