Schneider Electric ATV12H075M2

Schneider Electric ATV12H075M2 Variable Speed Drive

The Schneider Electric ATV12H075M2 is a compact, efficient AC drive within the Altivar 12 series, designed for simple machine applications requiring reliable speed control. Featuring advanced communication capabilities and efficient power management, this variable-speed drive offers versatility and precise control in a range of low-power applications. With a rated power of 0.75 kW (1 hp) and a 200-240 V single-phase power supply, the ATV12H075M2 is an ideal choice for applications needing compact, dependable motor control without complex setup or maintenance requirements.

Versatile Power and Control for Simple Machines

The ATV12H075M2 variable speed drive supports applications such as pumps, conveyors, fans, and other single-phase machines. Operating within a supply frequency of 50/60 Hz (±5%) and offering a supply voltage range of 200-240 V provides stable and efficient power output with minimal energy waste. The drive’s output current rating of 4.2 A ensures steady, reliable motor performance. At the same time, the adjustable switching frequency (2 to 16 kHz) enables fine-tuning to optimize performance, reduce noise, and manage energy usage. Its compact size and straightforward mounting make it a convenient option for panel or cabinet installations.

Integrated Modbus Communication for Seamless Integration

The ATV12H075M2 includes integrated Modbus communication, enabling easy connectivity with other devices and systems within a broader industrial network. The built-in 2-wire RS485 interface simplifies communication setup and seamlessly integrates with compatible PLCs and control systems. Utilizing RTU (Remote Terminal Unit) frame transmission, the ATV12H075M2 supports flexible system control, enabling operators to monitor and adjust drive settings remotely. This functionality enhances process efficiency and reduces the need for manual adjustments, providing a streamlined approach to drive management.

Advanced Features for Optimized Performance

One of the ATV12H075M2’s standout features is its robust range of control options. The drive offers a speed range of 1 to 20, providing flexibility in managing motor speeds according to application requirements. Additionally, the drive features a 10-bit analog input for precise frequency resolution, allowing for accurate motor control and smooth operation. For basic automation needs, the drive includes four discrete inputs, two discrete outputs, one analog input, and one analog output, enhancing its versatility in simple control schemes.

Built-in Protection and Durability

Engineered for longevity, the ATV12H075M2 is built with an IP20 protection rating, safeguarding it from dust and small particles. The drive’s design also incorporates an EMC (electromagnetic compatibility) filter, reducing electromagnetic interference and ensuring smooth operation in industrial environments. With Schneider Electric’s commitment to quality and robust design, this drive offers a reliable solution that can withstand the challenges of day-to-day industrial use. It also features overload protection to prevent system failures and safeguard connected motors.

Simple Setup and Maintenance

The ATV12H075M2 is designed to minimize setup time and simplify ongoing maintenance with an intuitive configuration process and clear on-device indications. Its cabinet-mounting design allows for quick installation, and the integrated EMC filter eliminates the need for external filtering components. Schneider Electric backs this product with a 2-year warranty, adding an extra layer of assurance for its durability and reliability.

Frequently Asked Questions (FAQ)

1. What is the power rating of the ATV12H075M2?

The ATV12H075M2 is rated for 0.75 kW (1 hp), making it suitable for a range of low-power applications such as small pumps, conveyors, and fans.

2. What kind of applications is this drive best suited for?

This drive is ideal for simple machine applications, especially those requiring essential variable speed control in industrial environments, such as fans, pumps, and small machinery.

3. Does the ATV12H075M2 support Modbus communication?

This model comes with integrated Modbus communication via a 2-wire RS485 interface, allowing easy connection to other Modbus-compatible devices.

4. What is the switching frequency range for this drive?

The switching frequency is adjustable between 2 and 16 kHz, with 4 to 16 kHz options when using a derating factor, providing flexibility in managing motor control and noise levels.

5. What is the protection rating of the ATV12H075M2?

The ATV12H075M2 has an IP20 protection rating, making it resistant to dust and small debris. It also includes an integrated EMC filter to reduce electromagnetic interference.

6. Is there a warranty for this drive?

Yes, this model is covered by a 2-year warranty when purchased through MRO Electric and Supply, ensuring dependable support and protection.

The Schneider Electric ATV12H075M2 AC drive combines simplicity, performance, and durability, making it a versatile solution for basic variable speed applications in industrial and commercial settings.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as Modicon and ABB.
