Schneider Electric ATS48C21Y

Schneider Electric ATS48C21Y Soft Starter

The Schneider Electric ATS48C21Y stands out as a sophisticated soft starter designed for asynchronous motors. For key specifications, applications, and notable features, continue reading.

Versatility in Motor Power

Designed for pumping and ventilation machines, the ATS48C21Y covers a wide range of applications with its power supply voltage spanning from 208 to 690 V. It flexibly handles motor powers ranging from 45 kW to 200 kW, making it a versatile solution for both severe and standard industrial scenarios.

Seamless Transitions in Various Applications

In severe applications, the ATS48C21Y accommodates motor powers of up to 90 kW at 440 V and 160 kW at 660 V. For standard applications, it offers options such as 55 kW at 230 V and 132 kW at 525 V. This adaptability ensures seamless soft start control for motors across different settings.

AC-53A Utilization Category for Robust Performance

With an AC-53A utilization category, this soft starter excels in both severe and standard applications. The torque-controlled start ensures smooth and controlled acceleration, providing reliability in diverse industrial environments. The nominal current for standard applications is 210 A, while for severe applications, it is 170 A.

Built for Protection and Flexibility

Featuring an IP00 degree of protection, the ATS48C21Y is not only robust against solid objects but also water-resistant. Its assembly style with a heat sink ensures effective heat dissipation, with an added option for an external bypass for enhanced flexibility.

Precise Control and Safety Features

The control circuit voltage, ranging from 110 - 15% to 230 + 10%, supports a frequency of 50/60 Hz. The soft starter includes relay outputs for motor-powered NO, end-of-starting relay NO, and fault relay NO. Logic outputs, configurable with 0 V common, add an extra layer of control precision.

Communication Capabilities

Equipped with Modbus protocol support, the ATS48C21Y facilitates seamless communication through a dedicated port with an RJ45 connector. The RS485 multidrop physical interface allows communication at varying transmission rates, supporting up to 31 nodes.

Compliance and Certification

The ATS48C21Y adheres to various international standards, including EN/IEC 60947-4-2, and boasts certifications from CCC, CSA, C-Tick, DNV, GOST, NOM 117, SEPRO, TCF, and UL. Its conformity to electromagnetic compatibility and environmental standards further establishes its reliability in diverse operating conditions.

Compact Design for Easy Integration

With dimensions of 380 mm (height), 320 mm (width), and 265 mm (depth) and a weight of 18.2 kg, the ATS48C21Y's compact design ensures easy integration into diverse industrial setups. Its robust construction and feature-rich design position it as a valuable component for precise motor control in industrial applications.

FAQs About the Schneider Electric ATS48C21Y Soft Starter

Q1: What is the main application of the Schneider Electric ATS48C21Y?

A1: The ATS48C21Y is primarily designed for soft-starting asynchronous motors, catering to pumping and ventilation machines in severe and standard industrial applications.

Q2: What is the power supply voltage range of the ATS48C21Y?

A2: The ATS48C21Y has a power supply voltage range of 208 to 690 V, providing flexibility for a variety of industrial setups.

Q3: Can the ATS48C21Y handle both severe and standard applications?

A3: Yes, the ATS48C21Y excels in severe and standard applications, thanks to its AC-53A utilization category and torque-controlled start, ensuring smooth and controlled acceleration.

Q4: What are the motor power options supported by the ATS48C21Y?

A4: The ATS48C21Y accommodates a wide range of motor powers, from 45 kW to 200 kW, making it suitable for various industrial scenarios.

Q5: Does the ATS48C21Y offer any protection features?

A5: Yes, the soft starter includes thermal protection for both the starter and the motor, as well as phase failure protection, ensuring the safety and longevity of the equipment.

Q6: What communication capabilities does the ATS48C21Y have?

A6: The ATS48C21Y supports Modbus protocol through a communication port with an RJ45 connector. The RS485 multidrop physical interface allows communication at varying transmission rates, supporting up to 31 nodes.

Q7: Can the ATS48C21Y be integrated into different setups?

A7: Absolutely. With dimensions of 380 mm (height), 320 mm (width), and 265 mm (depth), and a weight of 18.2 kg, the ATS48C21Y's compact design ensures easy integration into diverse industrial setups.

Q8: What certifications does the ATS48C21Y hold?

A8: The ATS48C21Y holds certifications from CCC, CSA, C-Tick, DNV, GOST, NOM 117, SEPRO, TCF, and UL, ensuring compliance with international standards and regulations.

Q9: How does the ATS48C21Y dissipate heat during operation?

A9: The soft starter features forced convection cooling, with an assembly style incorporating a heat sink for effective heat dissipation, ensuring optimal performance even in demanding conditions.

Q10: Is the ATS48C21Y suitable for environments with specific electromagnetic and environmental conditions?

A10: Yes, the ATS48C21Y meets electromagnetic compatibility standards and environmental requirements, making it a reliable choice in diverse operating conditions.
