AS-BDAU-202

2-year Warranty

Same Day Shipping

Schneider Electric AS-BDAU-202

MODICON TSX COMPACT ANALOG, OUTPUT, ISOL.

5/5
1 rating

Select Condition

Refurbished

2 in stock

New

3 in stock

$241.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part NumberAS-BDAU-202
ManufacturerSchneider Electric
TypeI/O Modules
Model #ASBDAU202
Warranty2 Year
Range18130-COMPACT 984 A210 I/O & CHASSIS
CategoryA120 AN OUT
Description2CH +/-10V+/-20MA
No. of channels2
Output voltage+10 Vdc
Resolution11 bits + sign
