Schneider Electric AS-B883-201

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.

Schneider Electric ASB883201

The Schneider Electric ASB883201, an integral component in the Modicon 984 Series, embodies precision and reliability as an 800-Series I/O Module designed for Analog Input with RTD capabilities. This technical description delves into the intricate specifications and features that define the ASB883201, offering a comprehensive understanding of its functionality within industrial automation.

Product Overview

Part Number: AS-B883-201

Manufacturer: Schneider Electric

Type: I/O Modules

Model #: ASB883201

Warranty: 2 Year

Terminal Connector and Description

Equipped with a warranty spanning two years, the ASB883201 includes a terminal connector, ensuring a holistic solution for seamless integration. Functioning as an Analog Input module with a focus on RTD input, it caters to both American and European standards with support for 100 Ω Platinum.

Inputs and Common Mode Voltage

With an impressive configuration of 8 inputs per module, the ASB883201 handles diverse data streams with finesse. The module exhibits a maximum common mode voltage tolerance of 7 Vdc/Vac (peak), a crucial specification for maintaining signal integrity in complex industrial environments.

Resolution and Program Control

Precision is a hallmark of the ASB883201, reflected in its resolution capabilities. It achieves a resolution of 1°C, 1°F, and 10 Ω under normal operation. Under program control, the module attains an even finer resolution of 0.1°C, 0.1°F, and 1 Ω, showcasing its adaptability to intricate control algorithms.

Update and Power-up Time

Operating with remarkable efficiency, the ASB883201 boasts an update time of 125 ms per selected channel, ensuring real-time data acquisition and responsiveness. During power-up, the module reaches operational status within a maximum time frame of 13 seconds, while the warm-up time is capped at 2 minutes, optimizing efficiency without compromising precision.

Power Requirements

The power profile of the ASB883201 is meticulously designed to balance performance and energy consumption. It requires +5 Vdc at 640 mA, +4.3 Vdc at 5 mA, and draws 0 mA from -5 Vdc. This power distribution underscores the module's efficiency and adaptability within power-constrained industrial setups.

Dimensions and Weight

Designed for space optimization, the ASB883201 demands just one slot within the system configuration. Weighing in at 4 lbs (1.8 kg), its compact form factor contributes to ease of installation and integration, particularly in applications where space is at a premium.

Performance Metrics

The ASB883201 exhibits a commitment to high-performance standards. Its update time of 125 ms per selected channel and a maximum of 1 second for all channels underscores its capability to handle dynamic industrial processes with agility and precision.

Conclusion

In conclusion, the Schneider Electric ASB883201 is a testament to Schneider Electric's dedication to excellence within industrial automation. As a crucial component in the Modicon 984 Series, this Analog Input module with RTD capabilities showcases precision, adaptability, and efficiency. From its fine resolution under program control to its rapid update times, the ASB883201 is engineered to meet the exacting demands of modern industrial processes. With a compact design, terminal connector inclusion, and a comprehensive 2-year warranty, it stands as a reliable and high-performance solution for Analog Input requirements in industrial automation systems.
