Siemens 6SL3224-0BE32-2UA0

Siemens 6SL3224-0BE32-2UA0 AC Drive: Comprehensive Overview

The Siemens 6SL3224-0BE32-2UA0 AC Drive, part of the versatile SINAMICS G120 family, is engineered to deliver exceptional performance in industrial motor control applications. With its advanced design, this AC drive supports various operational demands while maintaining high efficiency and reliability. From variable torque loads to precision vector control, this drive is ideal for industries that require robust motor management.

Key Specifications and Features

This AC drive operates at a line voltage of 380–480 V ±10% and is compatible with industrial 3-phase AC systems. Its broad input line frequency range of 47–63 Hz ensures adaptability to different power grids. It is designed for high performance and features a rated current of 63.00 A with a line reactor and 72.00 A without a line reactor. The drive supports a rated voltage of 400 V, making it suitable for various motor control applications.

The drive offers dual power ratings for versatility. In low overload (LO) conditions, it delivers up to 30.00 kW (40 hp), while in high overload (HO) scenarios, it provides 22.00 kW (30 hp). This adaptability ensures optimal performance across varying load requirements. Additionally, the maximum output current of 90.00 A accommodates demanding applications.

The 6SL3224-0BE32-2UA0 supports a pulse frequency of 4 kHz, enabling precise and smooth motor control. It provides output frequencies ranging from 0 to 550 Hz in V/f control and 0 to 200 Hz in vector control, making it suitable for applications requiring high precision and dynamic performance.

Design and Efficiency

The Siemens 6SL3224-0BE32-2UA0 AC Drive is built to provide superior reliability and efficiency. Its advanced vector control capabilities ensure precise torque and speed control, improving motors' performance across various industrial processes. The drive's compact and robust design is ideal for harsh industrial environments, offering durability and longevity.

This model includes state-of-the-art safety features and diagnostics to enhance operational safety and reduce downtime. Integrated protection mechanisms safeguard the drive and connected equipment against overloads, short circuits, and thermal stress, ensuring consistent performance over time.

Applications and Benefits

The 6SL3224-0BE32-2UA0 is widely used in manufacturing, automotive, and material handling industries. Typical applications include conveyors, pumps, fans, and compressors, where precise control and energy efficiency are critical. The dual overload capability ensures adaptability to both standard and high-demand operational scenarios, enhancing its versatility.

With a 2-year MRO Electric and Supply warranty and free shipping, customers can invest confidently, knowing they are backed by quality assurance and support.

Frequently Asked Questions (FAQs)

1. What type of AC drive is this?

This is a SINAMICS G120 AC drive designed for industrial motor control applications.

2. What is the input voltage range for this drive?

The input voltage range is 380–480 V ±10%, suitable for industrial systems.

3. Can this drive handle variable torque loads?

Yes, it is designed for variable torque loads such as pumps and fans and constant torque applications.

4. What is the maximum output current?

The drive can deliver a maximum output current of 90.00 A.

5. What is the rated power for low and high overload conditions?

The rated power is 30.00 kW (40 hp) for low overload and 22.00 kW (30 hp) for high overload.

6. Does it support vector control?

It supports vector control with an output frequency range of 0 to 200 Hz.

7. What safety features are included?

The drive includes protection against overloads, short circuits, and thermal stress to ensure safe operation.

8. Is a line reactor required for operation?

A line reactor is optional; the rated current differs based on its inclusion (63.00 A with the reactor, 72.00 A without).

9. Does the drive include a warranty?

Yes, it comes with a 2-year warranty from MRO Electric and Supply.

10. Is free shipping available?

Yes, this product offers free shipping, adding convenience for buyers.

This detailed overview of the Siemens 6SL3224-0BE32-2UA0 AC Drive emphasizes its features, applications, and advantages, demonstrating its value as a reliable and efficient solution for industrial motor control needs.

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.
