Siemens 6SL3210-1SE21-0UA0

Exploring the Siemens 6SL3210-1SE21-0UA0 SINAMICS S110 Power Module PM340

Siemens has established itself as a prominent player in the realm of industrial automation, and the 6SL3210-1SE21-0UA0, a SINAMICS S110 Power Module PM340, is a testament to its commitment to cutting-edge technology and reliability.

Rated Data:

Line Voltage: Operating in a range of 380 to 480 V with a ±10% tolerance, this power module adapts to a variety of industrial power systems.

Line Frequency: With a frequency range of 47 to 63 Hz, it aligns with standard power frequency specifications.

Rated Power: Delivering 4.00 kW of power, it is well-suited for applications demanding moderate power output.

Power Factor (λ): A high power factor of 0.96 indicates efficient power utilization.

Sound Pressure Level: Operating at a modest 50 dB, it ensures a relatively quiet operational environment.

Ambient Conditions:

Ambient Temperature: The module performs reliably in ambient temperatures up to 40 °C (104 °F).

Relative Humidity: With a tolerance of 95% at 40 °C, it exhibits resilience to varying humidity conditions.

Cooling: Utilizing increased air cooling facilitated by a built-in fan, the module ensures optimal operating temperatures.

General Tech. Specifications:

Number of Phases: Operating on 3 AC phases, it aligns with standard industrial power configurations.

Installation Altitude: Capable of functioning up to 1000 meters above sea level, it accommodates diverse installation environments.

Output Frequency for Servo Control: Ranging up to 330 Hz, it caters to applications requiring precise frequency control.

Mechanical Data:

Degree of Protection: With an IP20 rating and UL open-type designation, it balances protection with accessibility.

Net Weight: Weighing 4.00 kg, the module strikes a balance between robustness and portability.

Dimensions: Featuring a height of 165.0 mm, width of 270.0 mm, and depth of 153.0 mm, it exhibits a compact design suitable for various installation spaces.

Frame Size: Designated as FSB, it adheres to a specific sizing standard.

Connections and Conductor Specifications:

Motor Cable Length: Supporting cable lengths of up to 75 meters for unshielded and 50 meters for shielded configurations, it provides flexibility in motor placement.

Conductor Cross-Section: Accommodating conductor cross-sections from 1.00 to 6.00 mm², it caters to a range of cable types.

Connections: Employing screw-type terminals for both motor and line-side connections, ensures secure and reliable electrical connections.

MLFB-Ordering Data:

The Motor List for Function Blocks (MLFB) provides essential information for ordering and identification. The 6SL3210-1SE21-0UA0 signifies a specific configuration within the SINAMICS S110 Power Module PM340 series.

Frequently Asked Questions (FAQ) About Siemens 6SL3210-1SE21-0UA0 SINAMICS S110 Power Module PM340

Q1: What does the MLFB-Ordering Data "6SL3210-1SE21-0UA0" signify?

A1: The Motor List for Function Blocks (MLFB) code "6SL3210-1SE21-0UA0" denotes a specific configuration within the SINAMICS S110 Power Module PM340 series, serving as a unique identifier for ordering and identification purposes.

Q2: What is the operating voltage range of the power module?

A2: The power module operates within a voltage range of 380 to 480 V with a ±10% tolerance, making it adaptable to various industrial power systems.

Q3: Can you elaborate on the ambient conditions under which the module operates?

A3: Certainly, the module performs reliably in ambient temperatures up to 40 °C (104 °F) and maintains resilience with a relative humidity tolerance of 95% at 40 °C. The increased air cooling, facilitated by a built-in fan, contributes to optimal operating temperatures.

Q4: What is the rated power output of the 6SL3210-1SE21-0UA0 power module?

A4: The power module delivers a rated power output of 4.00 kW, making it well-suited for applications demanding moderate power output.

Q5: What frame size does the module adhere to, and what is its degree of protection?

A5: The module is designated as FSB in frame size and features a degree of protection with an IP20 rating and UL open-type designation, striking a balance between protection and accessibility.

Q6: What are the conductor specifications for motor cable connections?

A6: The module accommodates conductor cross-sections ranging from 1.00 to 6.00 mm² for motor cable connections. It supports cable lengths of up to 75 meters for unshielded and 50 meters for shielded configurations.

Q7: Does the 6SL3210-1SE21-0UA0 power module comply with any standards?

A7: Yes, the module complies with CE marking standards, low-voltage, and EMC guidelines, and holds cULus certification, ensuring adherence to recognized quality and safety standards.
