Siemens 6SL3210-1SB12-3UA0

Siemens 6SL3230-3YE38-1UB0: SINAMICS G120X Variable Frequency Drive

The Siemens 6SL3230-3YE38-1UB0, also known as the SINAMICS G120X, is a powerful variable frequency drive designed for industrial applications. Offering advanced features and robust performance, this drive delivers precise control over motor speed and torque, making it an ideal solution for various industrial processes.

Highly Rated Data:

The SINAMICS G120X operates on three AC phases with a line voltage range of 380 to 480 VAC and a line frequency of 47 to 63 Hz. It offers rated currents of 86.00 A for low overload (LO) and 78.00 A for high overload (HO) on the input side and 45.00 kW and 37.00 kW for LO and HO, respectively, on the output side. With a maximum output current of 122.00 A and a pulse frequency of 4 kHz, it ensures efficient and reliable operation even in demanding applications.

Versatile Control Options:

Equipped with advanced control algorithms, the SINAMICS G120X supports a wide range of control options for optimal motor performance. It offers output frequencies ranging from 0 to 200 Hz for vector control and from 0 to 550 Hz for V/f control. Additionally, it provides overload capabilities of 110% base load current for 60 seconds in a 300-second cycle time for LO and 150% x base load current for 60 seconds within a 600-second cycle time for HO, ensuring reliable operation under varying load conditions.

Comprehensive Communication and Connectivity:

The SINAMICS G120X features built-in communication interfaces, including USS, Modbus RTU, and BACnet MS/TP, enabling seamless integration with automation systems and industrial networks. It also offers multiple digital and analog inputs/outputs for flexible connectivity and control, making it adaptable to diverse application requirements.

Robust Construction and Environmental Adaptability:

Built to withstand harsh industrial environments, the SINAMICS G120X features a robust design with IP20/UL open-type protection. It operates efficiently in ambient temperatures ranging from -20 to 45°C during operation and -40 to 70°C during transport, ensuring reliable performance in extreme conditions. It is compliant with various standards, including UL, cUL, CE, and SEMI F47, meeting stringent requirements for safety and reliability.

Compact and User-Friendly Design:

Despite its powerful performance, the SINAMICS G120X boasts a compact design with dimensions of 275 mm (width) x 551 mm (height) x 248 mm (depth), making it easy to install in space-constrained environments. It features screw-type terminals for secure connections and offers straightforward installation and setup procedures, simplifying integration into existing systems.

FAQ

Q: What is the Siemens 6SL3230-3YE38-1UB0?

A: The Siemens 6SL3230-3YE38-1UB0 is a variable frequency drive known as the SINAMICS G120X. It is designed to control the speed and torque of three-phase AC motors in industrial applications.

Q: What are the key specifications of the Siemens 6SL3230-3YE38-1UB0?

A: The SINAMICS G120X operates on three AC phases with a line voltage range of 380 to 480 VAC and a line frequency of 47 to 63 Hz. It offers rated currents of 86.00 A for low overload (LO) and 78.00 A for high overload (HO) on the input side and 45.00 kW and 37.00 kW for LO and HO, respectively, on the output side. It also supports a pulse frequency of 4 kHz and has overload capabilities of 110% base load current for 60 seconds in a 300-second cycle time for LO and 150% x base load current for 60 seconds within a 600-second cycle time for HO.

Q: What communication options does the Siemens 6SL3230-3YE38-1UB0 offer?

A: The SINAMICS G120X has built-in communication interfaces, including USS, Modbus RTU, and BACnet MS/TP, allowing seamless integration with automation systems and industrial networks.

Q: What environmental conditions can the Siemens 6SL3230-3YE38-1UB0 operate in?

A: The SINAMICS G120X is designed to withstand harsh industrial environments and operates efficiently in ambient temperatures ranging from -20 to 45°C during operation and -40 to 70°C during transport. It also complies with various standards, including UL, cUL, CE, and SEMI F47, ensuring safety and reliability.

Q: Is the Siemens 6SL3230-3YE38-1UB0 easy to install and use?

A: Yes, the SINAMICS G120X features a compact design with screw-type terminals for secure connections, making installation straightforward. It also offers user-friendly interfaces and intuitive setup procedures, simplifying integration into existing systems.
