Siemens 6SL3210-1PE26-0AL0

Siemens 6SL3210-1PE26-0AL0 SINAMICS Introduction

The Siemens 6SL3210-1PE26-0AL0 SINAMICS Power Module PM240-2 is a pinnacle of efficiency and performance in industrial drive technology. Designed to meet the demanding requirements of modern manufacturing environments, this power module represents a versatile and reliable solution for controlling AC motors in various industrial applications. With its advanced features, robust construction, and compliance with international standards, the PM240-2 sets a new benchmark for power conversion and control.

Advanced Power Conversion Technology

The SINAMICS Power Module PM240-2 incorporates advanced power conversion technology to deliver precise control and efficient operation of AC motors. With a rated power of up to 30 kW (40 hp) in low overload and 22 kW (30 hp) in high overload, this power module provides exceptional performance for various industrial applications. Its high power factor (λ), offset factor (cos φ), and efficiency (η) ensure optimal energy utilization, reducing operating costs and environmental impact.

Flexible Input and Output Configurations

Equipped with three-phase AC input and output configurations, the PM240-2 power module offers flexibility to accommodate various system requirements. With a line voltage range of 380 to 480 V and a frequency range of 47 to 63 Hz, it can adapt to different power supply conditions, ensuring reliable operation in diverse industrial environments. The module's output frequency range of 0 to 200 Hz for vector control and 0 to 550 Hz for V/f control enables precise speed regulation and dynamic performance.

Enhanced Overload Capability

The PM240-2 power module features enhanced overload capability to effectively handle transient load conditions and peak power demands. With low overload and high overload ratings of up to 150% for short durations, the module can withstand heavy loads without compromising performance or reliability. This overload capability ensures smooth operation and protects the motor and drive system from damage during peak demand periods.

Robust Construction and Reliable Performance

Built to withstand the rigors of industrial environments, the PM240-2 power module features rugged construction and durable components. With an IP20 degree of protection and UL open-type design, it offers reliable performance even in harsh operating conditions. The module's integrated Class A filter minimizes electromagnetic interference (EMI), ensuring stable operation and compliance with international standards.

Comprehensive Ambient Conditions

The PM240-2 power module is designed to operate reliably in various ambient conditions. With an operating temperature range of -20 to 40°C for low overload and -20 to 50°C for high overload, it can withstand temperature variations without compromising performance. The module's internal air cooling system and screw-type terminal connections further enhance its suitability for industrial applications.

Compact Design and Easy Installation

Despite its powerful capabilities, the PM240-2 power module features a compact design and lightweight construction for easy installation and integration into control cabinets and enclosures. With dimensions of 200 x 472 x 237 mm (width x height x depth) and a net weight of 18.50 kg, it offers space-saving benefits without sacrificing performance or functionality. The module's screw-type terminal connections simplify installation and ensure secure electrical connections for reliable operation.

Frequently Asked Questions (FAQs) about the Siemens 6SL3210-1PE26-0AL0 SINAMICS Power Module PM240-2:

What is the Siemens 6SL3210-1PE26-0AL0 SINAMICS Power Module PM240-2?

The Siemens 6SL3210-1PE26-0AL0 is a power module controlling AC motors in industrial automation applications. It is part of the SINAMICS family of drives and offers advanced features for precise motor control and efficient operation.

What are the key features of the PM240-2 power module?

Key features include:

Advanced power conversion technology

Flexible input and output configurations

Enhanced overload capability

Robust construction for reliable performance

Comprehensive ambient condition tolerance

Compact design for easy installation

Compliance with international standards

What is the input and output voltage range of the PM240-2 power module?

The PM240-2 power module accepts three-phase AC input voltage ranging from 380 to 480 volts with a line frequency of 47 to 63 Hz. The output voltage is rated at 400V IEC or 480V NEC.

What is the rated power and current of the PM240-2 power module?

The PM240-2 power module's rated power is 30 kW (40 hp) in low overload and 22 kW (30 hp) in high overload. The rated current for the input side is 57.00 A (LO) and 47.00 A (HO), while for the output side, it is 60.00 A (LO) and 45.00 A (HO).

What is the overload capability of the PM240-2 power module?

The PM240-2 power module has a low overload capability of 1.1 times the rated output current for 57 seconds and 1.5 times the rated output current for 3 seconds. For high overload, it can handle 1.5 times the output current for 57 seconds and two times the output current for 3 seconds.

What are the ambient conditions in which the PM240-2 power module can operate?

The PM240-2 power module can operate in ambient temperatures ranging from -20 to 40°C for low overload and -20 to 50°C for high overload. It has a cooling requirement of 0.055 m³/s and complies with standards for operation at altitudes up to 1000 meters.

What are the mechanical specifications of the PM240-2 power module?

The PM240-2 power module is protected by IP20, making it suitable for indoor use. Its frame size is FSD, its net weight is 18.50 kg, and its dimensions are 200 x 472 x 237 mm (width x height x depth).

How can users connect the PM240-2 power module?

The PM240-2 power module features screw-type terminal connections for the line side, motor end, and DC link. It supports conductor cross-sections ranging from 10.00 to 35.00 mm² for line and motor connections and 2.50 to 16.00 mm² for the DC link.

What are the typical applications of the PM240-2 power module?

The PM240-2 power module is suitable for various industrial applications, including conveyor systems, pumps, fans, compressors, and machine tools. Its versatility and advanced features make it an ideal choice for various motor control tasks in industrial automation.

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.
