Siemens 6SL3210-1PE13-2AL1

Siemens 6SL32101PE132AL1 SINAMICS Power Module PM240-2: Precision and Efficiency in Motion Control

Unveiling the Advanced Features and Specifications of PM240-2

The Siemens 6SL32101PE132AL1, part of the SINAMICS Power Module PM240-2 series, is a remarkable solution in the realm of motion control. Renowned for its precision, efficiency, and versatility, this power module caters to various industrial applications where reliable motor control is essential.

Key Features and Specifications

Rated Power and Voltage: The PM240-2 boasts a rated power of 0.75 kW / 1.00 hp and a rated voltage of 400 V, making it suitable for a range of motor-driven applications. Its versatile capabilities contribute to efficient and precise motor control.

Frequency Control: With an output frequency range for V/f control from 0 to 200 Hz and for vector control from 0 to 550 Hz, the PM240-2 provides flexibility in adapting to different speed control requirements. This wide frequency range enhances its applicability across various industries.

Overload Capability: The power module exhibits an impressive overload capability. It can handle a high overload (HO) of 1.5 × rated output current for 57 seconds and a low overload (LO) of 1.1 × rated output current for the same duration, contributing to enhanced performance under varying load conditions.

Ambient Conditions: The PM240-2 is designed to operate efficiently in a broad range of ambient conditions. It can withstand temperatures ranging from -25 to 55 °C during operation and is equipped with internal air cooling for optimal performance.

Efficiency and Power Loss: The power module achieves a high efficiency of 96%, indicating its ability to convert electrical power to mechanical power with minimal losses. The low power loss of 0.04 kW further emphasizes its energy-efficient design.

Application Flexibility and Motor Control

The Siemens PM240-2 is engineered for flexibility and compatibility with various motor-driven applications. Its ability to handle a range of frequencies, coupled with advanced overload capabilities, makes it suitable for tasks such as conveyor systems, pumps, fans, and other machinery requiring precise and efficient motor control.

Mechanical Design and Compliance with Standards

The power module features a compact design with dimensions of 196.0 mm (width) × 73.0 mm (height) × 165.0 mm (depth). It adheres to the degree of protection IP20, providing a level of protection against solid objects. With a net weight of 1.50 kg, the PM240-2 is designed for easy integration into industrial systems.

Compliance with Standards and Certifications

The PM240-2 complies with various international standards, including CE marking, the low-voltage directive 2006/95/EC, UL, cUL, C-Tick (RCM), and SEMI F47. These certifications ensure that the power module meets stringent quality and safety standards.

Frequently Asked Questions (FAQ) about Siemens 6SL32101PE132AL1 SINAMICS Power Module PM240-2

1. What is the Siemens 6SL32101PE132AL1, and what distinguishes it in motion control?

The 6SL32101PE132AL1 is a member of the SINAMICS Power Module PM240-2 series by Siemens, designed for efficient and precise control of motors in industrial applications. Its distinguishing features include a wide frequency range, impressive overload capabilities, and compliance with international standards.

2. What is the rated power and voltage of the PM240-2?

The PM240-2 has a rated power of 0.75 kW / 1.00 hp and operates at a rated voltage of 400 V. This specification makes it suitable for various motor-driven applications where reliable and precise control is essential.

3. What frequency control options does the PM240-2 offer?

The power module provides a versatile frequency control range, with an output frequency range for V/f control from 0 to 200 Hz and for vector control from 0 to 550 Hz. This flexibility ensures adaptability to different speed control requirements in diverse industrial settings.

4. How does the PM240-2 handle overload conditions?

The PM240-2 exhibits impressive overload capabilities, including a high overload (HO) of 1.5 × rated output current for 57 seconds and a low overload (LO) of 1.1 × rated output current for the same duration. These features enhance performance under varying load conditions.

5. What are the ambient conditions for the operation of the PM240-2?

The power module is designed to operate efficiently in a broad range of ambient conditions. It can withstand temperatures ranging from -25 to 55 °C during operation, ensuring reliable performance in diverse industrial environments.

6. What is the efficiency of the PM240-2, and how does it contribute to energy savings?

The PM240-2 achieves a high efficiency of 96%, indicating its ability to convert electrical power to mechanical power with minimal losses. This high efficiency contributes to energy savings, making it an environmentally friendly and cost-effective choice.

7. What mechanical and design features does the PM240-2 exhibit?

The power module features a compact design with dimensions of 196.0 mm (width) × 73.0 mm (height) × 165.0 mm (depth). It adheres to the degree of protection IP20, protecting solid objects. With a net weight of 1.50 kg, the PM240-2 is designed for easy integration into industrial systems.

8. Does the PM240-2 comply with international standards and certifications?

The PM240-2 complies with various international standards, including CE marking, the low-voltage directive 2006/95/EC, UL, cUL, C-Tick (RCM), and SEMI F47. These certifications ensure that the power module meets stringent quality and safety standards, making it a reliable choice for industrial applications.
