Siemens 6SL3120-2TE21-0AA0

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry AC Drives from other manufacturers such as FANUC and Yaskawa.

Siemens 6SL3120-2TE21-0AA0/0AD0 Motor Module: Precision in Power and Performance

Rated Data and Output Characteristics

The Siemens 6SL3120-2TE21-0AA0/0AD0 Motor Module is engineered to deliver precise and efficient performance in diverse industrial applications. With a rated output current of 2 x 12.0 A and a DC link voltage spanning from 510 to 720 V, it caters to a spectrum of power requirements. The base load current IH is set at 2 x 9.0 A, with a maximum rated value IN of 2 x 27.0 A. The electronics power supply is robust, ensuring a stable current demand, with a maximum of 0.90 A for 24 V DC.

Dynamic Frequency Control and Capacitance

For servo control, the module supports an output frequency of 4.00 kHz, while for vector control and V/f control, it achieves frequencies of 300 Hz and 600 Hz, respectively. The DC-link capacitance stands at 220 µF, ensuring smooth and continuous power delivery. With a rated pulse frequency of 650 Hz, it meets the demands of dynamic applications with precision.

Ambient Conditions and Compliance with Standards

The 6SL3120-2TE21-0AA0/0AD0 operates optimally within an ambient temperature range of 0 to 40 °C (32 to 104 °F) and up to an altitude of 1000 m (3281 ft) without derating. Its compliance with Safety Integrated standards, SIL 2 (IEC 61508), PL d (EN ISO 13849-1), and Category 3 (EN ISO 13849-1) underscores its commitment to safety in industrial environments. It carries the CE and cULus certifications.

Mechanical Data and Construction

The motor module boasts a booksize construction with a width of 380.00 mm (14.96 in), a height of 270.00 mm (10.63 in), and a depth of 50.00 mm (1.97 in). With a net weight of 4.7 kg (10.36 lb), it combines robustness with a compact design. The degree of protection is rated at IP20/UL open type, ensuring resistance to dust and other environmental factors. The module is designed for ease of installation, featuring shielded and unshielded connections with a PE connection M5 screw.

Sound Pressure Level and Power Loss

In terms of acoustics, the module maintains a sound pressure level of 60.0 dB at 1m. The power loss, typ./max., is meticulously managed, ensuring optimal efficiency in operation. The booksize construction, coupled with advanced cooling mechanisms, contributes to maintaining a low sound profile during operation.

Conclusion: Precision in Design, Power, and Safety

In conclusion, the Siemens 6SL3120-2TE21-0AA0/0AD0 Motor Module stands as a technological powerhouse, integrating precision in design, power delivery, and safety standards. From its dynamic frequency control capabilities to its compliance with international safety standards, every aspect of this module is crafted for optimal performance in industrial automation. Its compact construction, advanced cooling, and meticulous attention to acoustics make it a reliable and efficient choice for applications demanding precision and reliability.
