SINAMICS S120 DRIVE SYSTEM CUA32 CONTROL UNIT ADAPTER- AT 24V DC: 0.15A
3 in stock
Ships Today
Free Shipping
2 Year warranty
| Part Number | 6SL3040-0PA01-0AA0 |
| Manufacturer | Siemens |
| Type | Controllers |
| Model # | 6SL30400PA010AA0 |
| Warranty | 2 Year |
| Category | Control Unit Adapter |
| Max consumed current at 24 V DC | 0.65 A |
| Max conductor cross-section | 2.5 mm² (AWG 14) |
| Max power loss | 2.6 W |
| PE connection | M4 screw |
| Max cable length TTL encoder 2) | 328.08 ft |
| Max cable length HTL encoder unipolar signal 1 | 328.08 ft |
| Max cable length HTL encoder bipolar signal | 984.25 ft |
| Max cable length SSI encoder | 328.08 ft |
| Height | 6.53 in |
| Width | 2.87 in |
| Depth | 1.47 in |
| Encoder evaluation | optional incremental encoder TTL/HTL or encoder SSI without incremental signals |
| Input current TTL encoder | 2 … 10 mA |
| Input current HTL encoder | 2 … 10 mA |
| Max. load current at 24 V encoder supply | 0.35 A |
| Max. load current at 5 V encoder supply | 0.35 A |
| Max Encoder frequency | 500 Hz |
| SSI absolute position resolution | 30 bit |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 6SL3040-0PA01-0AA0 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 6SL3040-0PA01-0AA0 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 6SL3040-0PA01-0AA0, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 6SL3040-0PA01-0AA0 for credit when ordering from MRO Electric
The Siemens 6SL3040-0PA01-0AA0 is a robust control unit adapter designed to enhance the functionality and performance of industrial systems. As part of Siemens' advanced automation technology, this adapter is engineered to meet the demanding needs of industrial applications that require precise control and reliable communication between encoders and controllers. Its compatibility with multiple encoder types—such as TTL, HTL, and SSI—makes it a versatile solution for diverse use cases. The unit's compact design and flexible installation options also make it ideal for space-constrained environments.
With a 2-year warranty provided by MRO Electric and Supply and free shipping included, the Siemens 6SL3040-0PA01-0AA0 offers both reliability and convenience. This control unit adapter is an excellent choice for professionals who need a high-performance device that can seamlessly integrate into existing automation systems while ensuring long-term reliability.
The Siemens 6SL3040-0PA01-0AA0 operates on a 24 V DC power supply and consumes a maximum current of 0.65 A. Its efficient design minimizes energy usage while ensuring stable operation, with a maximum power loss of just 2.6 W. The unit's low power consumption is particularly beneficial for systems prioritizing energy efficiency and long-term sustainability.
The device supports a maximum conductor cross-section of 2.5 mm² (AWG 14), providing flexibility for various wiring configurations. Additionally, the PE (protective earth) connection is made through an M4 screw, ensuring secure grounding for enhanced safety and reliability in industrial environments.
The 6SL3040-0PA01-0AA0 is compatible with multiple encoders, including TTL, HTL, and SSI encoders. This adaptability makes the control unit ideal for various industrial automation applications. The device supports TTL and HTL signals for incremental encoders, while for absolute encoders, it supports SSI without incremental signals. The maximum cable lengths for different encoders are impressive, with up to 984.25 ft for HTL encoders with bipolar signals, ensuring long-distance communication capabilities.
The unit provides a maximum encoder frequency of 500 Hz, allowing for high-speed data transmission, essential for applications requiring precise real-time control. The SSI absolute position resolution reaches up to 30 bits, offering exceptional accuracy for position measurements, making the device suitable for highly detailed monitoring and control applications.
The Siemens 6SL3040-0PA01-0AA0 control unit adapter is designed with compact dimensions, measuring 6.53 inches in height, 2.87 inches in width, and 1.47 inches in depth. This small footprint allows for easy integration into control panels or other industrial systems where space may be limited. Despite its compact size, the unit is engineered to provide reliable performance in demanding environments.
The 6SL3040-0PA01-0AA0's durable construction ensures long-term reliability, even in challenging industrial conditions. Its rugged design helps protect the internal components from environmental factors, ensuring continuous operation over time.
The unit is easy to install and integrate into existing automation systems. It supports flexible configurations, including the evaluation of optional incremental encoders, allowing for tailored solutions depending on the application's specific needs. The unit's versatility suits various industries, from manufacturing to process control.
What types of encoders are compatible with the 6SL3040-0PA01-0AA0?
The Siemens 6SL3040-0PA01-0AA0 is compatible with TTL, HTL, and SSI encoders. It supports incremental (TTL/HTL) and absolute (SSI without incremental signals) encoders, making it versatile for various industrial applications.
What is the maximum cable length for the connected encoders?
The maximum cable length is 328.08 ft for TTL and HTL encoders with unipolar signals, 984.25 ft for HTL encoders with bipolar signals, and 328.08 ft for SSI encoders.
What is the input current range for TTL and HTL encoders?
The input current for both TTL and HTL encoders is between 2 to 10 mA.
What is the maximum load current for the encoder supply?
The unit supports a maximum load current of 0.35 A for 24 V and 5 V encoder supplies.
What is the maximum encoder frequency the unit can handle?
The Siemens 6SL3040-0PA01-0AA0 can handle a maximum encoder frequency of 500 Hz, making it suitable for high-speed data transmission and control.
What is the power consumption of the 6SL3040-0PA01-0AA0?
The unit consumes a maximum of 0.65 A at 24 V DC and has a power loss of 2.6 W, making it energy-efficient.
What warranty does the 6SL3040-0PA01-0AA0 come with?
The Siemens 6SL3040-0PA01-0AA0 comes with a 2-year MRO Electric and Supply warranty, providing peace of mind and supporting any technical issues. Free shipping is also available with every purchase.
Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry Controllers from other manufacturers such as FANUC and Yaskawa.
Check out the rest of our Siemens product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like 6SL3040-0PA01-0AA0, take a look at more from our Controllers line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our 6SL3040-0PA01-0AA0 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
