Siemens 6SE6440-2UD22-2BA1

Siemens Part Number 6SE6440-2UD22-2BA1

The Siemens Part Number 6SE6440-2UD22-2BA1 is an HMI (Human Machine Interface) device designed for industrial automation applications. Manufactured by Siemens, a renowned company in the field of automation and control systems, this HMI provides a user-friendly interface for monitoring and controlling processes. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry HMIs from other manufacturers such as FANUC and Yaskawa.

The 6SE6440-2UD22-2BA1 HMI is a versatile device that supports a wide range of applications. It comes with a 2-year warranty, ensuring reliability and peace of mind for the users.

Features

The HMI is designed to operate in a three-phase AC power system with a line voltage ranging from 380 to 480 V with a tolerance of ±10%. It supports a line frequency of 47 to 63 Hz, making it compatible with various power supply systems commonly found in industrial settings.

In terms of output, the 6SE6440-2UD22-2BA1 HMI provides three-phase AC output with a rated voltage of 480 V. It delivers a rated power of 2.20 kW or 3.00 hp, with a rated current of 5.90 A in high overload (HO) conditions. The pulse frequency of the device is 4000 Hz, allowing for precise control and operation.

The HMI supports output frequency for V/f (Voltage to frequency) control in the range of 0 to 650 Hz, enabling flexible motor control and speed regulation. This feature is particularly useful in applications that require precise control over motor speed.

Protection

With an IP20 degree of protection, the 6SE6440-2UD22-2BA1 HMI offers adequate protection against dust and solid objects, making it suitable for most industrial environments. It is important to note that this HMI should be installed in a suitable enclosure to provide additional protection against moisture and other external elements.

Design

The physical dimensions of the HMI are compact, with a size classified as FSB. It has a net weight of 3.30 kg, making it lightweight and easy to handle during installation and maintenance. The device has a width of 149.0 mm, a height of 202.0 mm, and a depth of 172.0 mm, allowing for flexible installation in space-constrained environments.

Connection

The 6SE6440-2UD22-2BA1 HMI offers a range of digital and analog inputs and outputs, enhancing its functionality and versatility. It provides six standard digital inputs, allowing for the connection of various sensors and switches to monitor different aspects of the industrial process. Additionally, it offers three relay outputs, which can be used to control external devices or trigger alarms based on specific conditions.

Furthermore, the HMI features two analog inputs and two analog outputs, enabling the connection of analog sensors or actuators for more precise control and monitoring. This capability is valuable in applications that require continuous measurement and control of analog variables.

The 6SE6440-2UD22-2BA1 HMI also includes a PTC/KTY interface, which allows for connection with temperature sensors such as PTC (Positive Temperature Coefficient) or KTY (Thermistor). This interface facilitates temperature monitoring and control, adding another dimension of functionality to the device.

FAQs for Siemens 6SE6440-2UD22-2BA1 HMI

1. What is the Siemens 6SE6440-2UD22-2BA1 used for?

The Siemens 6SE6440-2UD22-2BA1 is a Human Machine Interface (HMI) used in industrial applications to control and monitor automation systems. It is commonly used with SINAMICS drive systems, enabling users to configure, monitor, and control motor drives for various industrial processes.

2. What are the voltage and current ratings for this HMI?

The 6SE6440-2UD22-2BA1 operates with a line voltage between 380-480 V AC ±10% and a line frequency of 47-63 Hz. It is rated for a current of 7.50 A in High Overload (HO) mode for input, with a rated output voltage of 480 V and an output current of 5.90 A in HO mode.

3. How many phases does the 6SE6440-2UD22-2BA1 support?

This HMI supports three-phase AC input and output, which is standard for industrial applications that require high power and efficient energy distribution.

4. What are the output power specifications?

The Siemens 6SE6440-2UD22-2BA1 has a rated power output of 2.20 kW or 3.00 horsepower (hp) in High Overload mode. This makes it suitable for controlling motors in medium to large-scale industrial environments.

5. What degree of protection does the 6SE6440-2UD22-2BA1 offer?

The 6SE6440-2UD22-2BA1 is rated with an IP20 degree of protection, meaning it protects solid objects larger than 12.5 mm but is not waterproof. This makes it suitable for installation in controlled environments where it is not exposed to dust or water.

6. How many digital and analog inputs/outputs does the HMI have?

This HMI has six standard digital inputs and two analog and two analog outputs. Additionally, it includes three relay outputs, making it highly flexible for various control and monitoring configurations in industrial automation systems.

7. What is the size and weight of the 6SE6440-2UD22-2BA1?

The Siemens 6SE6440-2UD22-2BA1 has a compact form factor, measuring 149.0 mm in width, 202.0 mm in height, and 172.0 mm in depth. Its net weight is 3.30 kg, making it relatively lightweight and easy to install within existing setups.

8. What is the pulse frequency for this HMI?

The 6SE6440-2UD22-2BA1 has a pulse frequency of 4000 Hz, which helps control the output signal for efficient and smooth motor operation in applications such as conveyor systems, pumps, and fans.

9. What is the output frequency range for V/f control?

The output frequency for V/f (voltage/frequency) control ranges from 0 to 650 Hz, providing a wide range of operational flexibility to control motor speed and torque for various industrial tasks.

10. Does the Siemens 6SE6440-2UD22-2BA1 have any unique protection interfaces?

Yes, the HMI includes a PTC/KTY interface, which provides temperature monitoring for the motor. This protects the engine from overheating, improving operational safety and longevity.

11. Is this product covered by a warranty?

Yes, the Siemens 6SE6440-2UD22-2BA1 is covered by a 2-year warranty from MRO Electric and Supply, ensuring that the product is protected for two years from the date of purchase.

12. Does MRO Electric offer free shipping for this HMI?

Yes, MRO Electric offers free shipping for the Siemens 6SE6440-2UD22-2BA1, which can help reduce the overall cost when purchasing the unit.

13. What standards does this HMI meet?

The Siemens 6SE6440-2UD22-2BA1 complies with industry standards to ensure reliable performance in industrial applications. It is designed for efficiency and meets the relevant certifications for safety and quality in automation.
