Part Number | 6EP1436-3BA00 |
Manufacturer | Siemens |
Type | Power Supplies |
Model # | 6EP14363BA00 |
Warranty | 2 Year |
Range | SITOP |
SITOP | Modular |
Power supply | 24 V/20 A |
Input | 3-phase AC |
Supply voltage | 400 V |
Supply voltage | 320 … 550 V @ AC |
Overvoltage resistance | 2.3 × Vin rated, 1.3 ms |
Mains buffering | 6 ms |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 6EP1436-3BA00 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 6EP1436-3BA00 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 6EP1436-3BA00, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty 6EP1436-3BA00 for credit when ordering from MRO Electric
The SITOP modular 20 A Stabilized power supply module 6EP1436-3BA00 is manufactured by Siemens, an industry leader in automation. A robust power supply module, the SITOP PSU300m/300B is made for use with automated machines and systems. It is a primary-clocked power supply unit that is manufactured to connect seamlessly to a 3-phase AC line supply. The DC voltage is electronically regulated and is able to be set by way of a built-in potentiometer. There are LED displays on the SITOP 6EP1436-3BA00 that indicate the operating status. You can access the operating state of this unit as it is processed by way of the signaling contact. The potentiometer is accessed at the module’s output. This stabilized technology power supply module includes several beneficial key features. These products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry Power Supplies from other manufacturers such as FANUC and Yaskawa.
The Siemen 6EP1436-3BA00 features a line input connection and a DC output connection on the front lower portion. There are three things to note about the output of this SITOP module. The output is isolated, no-load proof, and short circuit proof. The signaling contacts are beside the input/output connections.
Next to the signaling contacts on the lower front part of the module is the potentiometer followed by the pilot lamps.
The selector switch is located on the underneath portion of the unit on the left front side. On the bottom rear of the SITOP module, you will find the DIN rail slider. Another key feature of this Siemens unit is that the PSU300B is optimized to charge batteries.
To establish a connection to the supply voltage of the line input terminals, use the line input terminal connection. There is one screw terminal for the line input on this module. You will use the output terminals for connecting to the loads that you want to be supplied with power. This unit includes two screw terminals for output + and two screw terminals for output -. You also have available to you two signaling contact screws. This module is made for ambient temperature between -25 (-10)...+70 °C.
Using the SIEMENS SITOP 6EP1436-3BA00 you will find a power boost during operation 300% for 25 ms. Lateral mounting clearances are unnecessary for this unit which is an important consideration and a space-saving advantage. It boasts 150 % of extra power when you switch on high input currents for extra current loads. The 48 V / 10 A of this unit allows small cable cross-sections. You have the option of selecting short-circuit behavior. Also available by way of the soft characteristic curve is parallel switching or battery charging. Either can be selected. The three LEDs let you know the operating state in a clear, easily visible way. This module also has integrated signaling contact "DC 12 V O.K." / "DC 24 V O.K." / "DC 48 V O.K." Another useful feature is the ability to add to this module if your needs change. This can be done by adding reliable power supply expanding units. Some supplementary modules include a redundancy module, a selectivity module, and a buffer module. In addition to that, there are SITOP DC-UPS modules.
Check out the rest of our Siemens product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like 6EP1436-3BA00, take a look at more from our Power Supplies line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our 6EP1436-3BA00 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
