6AV6642-0DC01-1AX1

2-year Warranty

Same Day Shipping

Siemens 6AV6642-0DC01-1AX1

SIMATIC OP177B 6 DP BLUE MODE STN DISPLAY TOUCH AND KEYS MPI-/PROFIBUS-DP

5/5
2 ratings

Select Condition

Refurbished

Request Quote

New

1 in stock

$3,997.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number6AV6642-0DC01-1AX1
ManufacturerSiemens
TypeHMIs
Model #6AV66420DC011AX1
Warranty2 Year
DesignSTN
Diagonal5.7 in.
Size120 mm x 90 mm
ConfigurableYes
Style Display4 blue levels
Greyscale4
Color Blue Levels
Horizontal resolution320
Verticle resolution240
BacklightingMTBF ~ 50000 hours
ControlMembrane Keyboard
Operation OptionKey/Touch
Keys32 function keys
ConnectionUSB
LED Function keys 26 with LED
Touch screenAnalog and resistive
Supply voltage24 V DC
Input Current0.24 A
Inrush current0.5 A².s
Processor ARM 200 MHz
MemoryFlash/RAM
User data2048 KB usable memory
ClockSynchronizable, no battery backup
InterfacesRS232 optional, 1 x RS422, 1 x RS485 (max. 12 Mbit/s)
Multimedia card/SD card slotcombined, as of E version 016 in conj. with WinCC flex. 2008 SP1
CertificationsCE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, cULus, EX Zone 2, EX Zone 22, C-TICK, NEMA 4x, NEMA 12
Hazardous Area UseEX zone 2 Yes EX zone 22
Mounting positionVertical
Max angle+/- 35 °
Storage-20 °C to +60 °C
OSWindows CE

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 6AV6642-0DC01-1AX1 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 6AV6642-0DC01-1AX1 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 6AV6642-0DC01-1AX1, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 4lbs

Want it shipped tomorrow?

  • Order within the next 18 hours and 22 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 6AV6642-0DC01-1AX1 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Siemens 6AV6642-0DC01-1AX1 Overview

Siemens 6AV6642-0DC01-1AX1 HMI: A Comprehensive Overview

The Siemens 6AV6642-0DC01-1AX1 is an advanced Human-Machine Interface (HMI) device that delivers robust functionality and seamless performance for industrial automation systems. Manufactured by Siemens, a global automation and electrical engineering leader, this HMI is designed to enhance communication between operators and machines in various industrial settings. With a wide array of features, from display options to connectivity, it offers versatile usability, reliability, and safety standards. MRO Electric and Supply offers a two-year warranty on this product with free shipping, ensuring customer satisfaction.

Display and Design

The Siemens 6AV6642-0DC01-1AX1 features a 5.7-inch STN (Super Twisted Nematic) display that provides clear visibility, ideal for complex industrial environments. The display's 5.7-inch (120 mm x 90 mm) diagonal size offers ample screen space for viewing data and operational parameters. Configurable for different industrial applications, it has four blue levels and greyscale capabilities, enhancing clarity even in low-light conditions. The display resolution is 320x240 pixels, offering crisp and reliable visualization for critical operations.

This HMI is built to last, with a backlighting system boasting an impressive Mean Time Between Failures (MTBF) of approximately 50,000 hours. This ensures continuous operation with minimal downtime, making it highly reliable in demanding industrial settings.

Control and Operation

The Siemens 6AV6642-0DC01-1AX1 offers flexible control options with both key-based and touch-based operations. The membrane keyboard provides 32 function keys, 26 of which are equipped with LED indicators for easy identification and operation. The analog and resistive touch screens provide a responsive performance that allows operators to interact seamlessly with the system. This dual input method enhances user control, making it ideal for various industrial applications, from manufacturing to process automation.

Power and Processor

The Siemens 6AV6642-0DC01-1AX1's power requirements are minimal, with a supply voltage of 24 V DC and an input current of 0.24 A. Its inrush current is rated at 0.5 A².s, making it energy-efficient while delivering reliable performance. The unit is driven by a 200 MHz ARM processor, which ensures smooth operation, data processing, and command execution. This high-performance processor allows the HMI to handle complex data visualization tasks and industrial commands with ease.

Memory and Storage

With 2048 KB of usable memory, this HMI offers sufficient storage for user data and configuration files. The memory is based on flash/RAM technology, providing stability and ensuring that critical data is retained even during power outages. A multimedia card/SD card slot is available for external storage, enabling users to expand the device's memory capacity. The card slot can also be used with WinCC flexible 2008 SP1, providing advanced configuration and communication options.

Connectivity and Interfaces

The Siemens 6AV6642-0DC01-1AX1 is designed to support multiple communication protocols, making it highly versatile in different industrial networks. It has optional RS232, RS422, and RS485 interfaces, supporting data transfer rates of up to 12 Mbit/s. The USB connection ensures the device can easily interface with modern industrial systems for data exchange and updates.

Certifications and Safety Standards

This HMI is certified for use in a wide range of hazardous environments, with approvals from CE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, cULus, EX Zone 2, and EX Zone 22. The Siemens 6AV6642-0DC01-1AX1 also complies with NEMA 4x and NEMA 12 standards, ensuring its durability in harsh conditions. These certifications make the device suitable for use in hazardous zones and under extreme environmental conditions, providing safety and performance.

Mounting and Environmental Conditions

The Siemens 6AV6642-0DC01-1AX1 is designed for vertical mounting and can be installed at a maximum angle of +/—35°. Its wide storage temperature range, from -20°C to +60°C, ensures that it can be safely stored and operated in extreme environmental conditions.

Operating System and Software

The device runs on Windows CE, a highly reliable operating system that is compatible with various industrial software applications. Users can configure the HMI using WinCC flexible 2008 SP1, which provides them with advanced tools to optimize performance.

FAQs for Siemens 6AV6642-0DC01-1AX1 HMI

Q1: What is the display size and resolution of the Siemens 6AV6642-0DC01-1AX1 HMI?

A1: The Siemens 6AV6642-0DC01-1AX1 features a 5.7-inch STN display with a resolution of 320x240 pixels. This provides clear and detailed visibility and is ideal for monitoring industrial processes and data visualization.

Q2: What type of control options does this HMI offer?

A2: This HMI provides both key-based and touch-based control options. It includes a membrane keyboard with 32 function keys, 26 of which have LED indicators. Additionally, the touch screen is analog and resistive, allowing for responsive and accurate interaction with the system.

Q3: What is the power supply requirement for the 6AV6642-0DC01-1AX1 HMI?

A3: The Siemens 6AV6642-0DC01-1AX1 requires a supply voltage of 24 V DC, with an input current of 0.24 A and an inrush current of 0.5 A².s. It is designed to operate efficiently while maintaining reliable performance in industrial settings.

Q4: What communication interfaces are available on this HMI?

A4: The device has multiple communication interfaces, including optional RS232, RS422, and RS485. These interfaces allow flexible communication with other industrial devices, with data transfer rates of up to 12 Mbit/s. It also includes a USB connection for additional connectivity.

Q5: Is the Siemens 6AV6642-0DC01-1AX1 certified for use in hazardous environments?

A5: Yes, this HMI is certified for use in hazardous environments. It carries certifications such as CE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, cULus, EX Zone 2, and EX Zone 22. It also complies with NEMA 4x and NEMA 12 standards, ensuring durability and safety in extreme conditions.

Q6: What is the estimated lifespan of the backlighting system?

A6: The backlighting system of the Siemens 6AV6642-0DC01-1AX1 has a Mean Time Between Failures (MTBF) of approximately 50,000 hours. This ensures long-term reliability and minimal downtime in industrial operations.

Q7: What type of processor is used in this HMI?

A7: The Siemens 6AV6642-0DC01-1AX1 is powered by a 200 MHz ARM processor. This processor ensures smooth data processing and efficient task execution, making it suitable for complex industrial applications.

Q8: What storage options are available for user data?

A8: The HMI offers 2048 KB of usable memory for user data storage. It also includes a multimedia card/SD card slot, which can expand the device’s storage capacity or for advanced configuration through WinCC flexible 2008 SP1.

Q9: What is the operating temperature range of this HMI?

A9: The Siemens 6AV6642-0DC01-1AX1 can be stored in temperatures ranging from -20°C to +60°C. This wide temperature range ensures that the device can be safely stored and operated in various industrial environments.

Q10: Does this HMI come with a warranty?

A10: MRO Electric and Supply offers a 2-year warranty on the Siemens 6AV6642-0DC01-1AX1. Additionally, the product is available with free shipping.
