6AV6641-0BA11-0AX1

2-year Warranty

Same Day Shipping

Siemens 6AV6641-0BA11-0AX1

SIMATIC OPERATOR PANEL OP77A BACKLIT LC DISPLAY, 4.5 DISPL. W. GRAPHICS

5/5
1 rating

Select Condition

Refurbished

2 in stock

$1,279.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number6AV6641-0BA11-0AX1
ManufacturerSiemens
TypeHMIs
Model #6AV66410BA110AX1
Warranty2 Year
DesignOP 77A
Disply STN
Screeen Diag4.5 in.
Colors 2 black/white
Resolution (H)160 pixel
Resolution (V)64 pixel
MTBF backlighting100 000 h
MountingVerical
Max Mount Angle80°
Supply VoltageDC
Input Current0.2 A
Processor ARM
Starting current inrush I²t0.5 A²·s
MemoryFlash/RAM
User Data256 kbyte
Interfaces/bus type1x RS 422, 1x RS 485 (max. 1.5 Mbit/s)
IP FrontIP65
IP RearIP20
Max Ambient Temp50° C
Certificate of suitabilityCE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, cULus

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 6AV6641-0BA11-0AX1 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 6AV6641-0BA11-0AX1 we also repair a wide range of other Siemens products, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 6AV6641-0BA11-0AX1, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped tomorrow?

  • Order within the next 18 hours and 25 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 6AV6641-0BA11-0AX1 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Siemens 6AV6641-0BA11-0AX1 Overview

Siemens 6AV6641-0BA11-0AX1 Overview

The Siemens 6AV6641-0BA11-0AX1 is an industrial Human-Machine Interface (HMI) facilitating smooth interaction between operators and automation systems. Part of the OP 77A series, this HMI is ideal for applications requiring a reliable and robust interface that operates efficiently in industrial environments. The model is engineered to provide clear and precise control options while maintaining a user-friendly design.

Design and Display Features

This model comes equipped with a 4.5-inch black-and-white STN display with a resolution of 160 pixels horizontally and 64 pixels vertically. While it offers just two colors—black and white—this is sufficient for many industrial applications where complex color schemes are unnecessary. The display is built to be durable and long-lasting, boasting an impressive mean time between failures (MTBF) for backlighting of 100,000 hours. This ensures that the HMI will remain functional and legible for extended periods in demanding conditions.

Mounting and Installation

Designed for vertical mounting, the 6AV6641-0BA11-0AX1 has a maximum mounting angle of 80 degrees. This flexibility allows for various installation configurations, making it suitable for multiple control cabinets and equipment layouts. It also supports RS 422 and RS 485 interfaces with a maximum data transmission rate of 1.5 Mbit/s, enabling versatile communication options.

Power and Processing Capabilities

The Siemens OP 77A is powered by DC voltage and requires an input current of approximately 0.2 A. It is equipped with an ARM processor, which offers sufficient computing power for executing HMI functions reliably. The unit can handle a starting current inrush of up to 0.5 A²·s, ensuring stable operation during power-up. This HMI has 256 KB of user memory, combining flash and RAM storage to efficiently manage applications and system data.

Durability and Certification

The Siemens 6AV6641-0BA11-0AX1 meets stringent industrial standards, with the front side rated at IP65 and the rear side at IP20. The IP65 rating ensures that the HMI’s front panel is resistant to dust and low-pressure water jets, making it ideal for harsh industrial environments. It is certified by various standards bodies, including CE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, and cULus, highlighting its suitability for diverse applications and global use.

Temperature and Environmental Adaptability

The model is engineered to withstand temperatures up to 50°C, making it suitable for various industrial settings where high ambient temperatures are a concern. This wide temperature range ensures reliable operation in various manufacturing and processing environments.

Warranty and Support

The Siemens 6AV6641-0BA11-0AX1 comes with a 2-year warranty from MRO Electric and Supply, offering users peace of mind regarding the quality and reliability of the product. This warranty covers manufacturing defects and potential issues that may arise during the warranty period.

Frequently Asked Questions (FAQs)

What type of display does the 6AV6641-0BA11-0AX1 have?

The 6AV6641-0BA11-0AX1 features a 4.5-inch STN display with two colors (black and white). The display resolution is 160 x 64 pixels, which provides clear and easy-to-read information.

How durable is the backlighting of this HMI?

The backlighting in this HMI has an MTBF of 100,000 hours, ensuring a long operational life without frequent maintenance or replacements.

What communication interfaces are available?

This HMI supports both RS 422 and RS 485 interfaces, which allow for reliable data transmission at speeds up to 1.5 Mbit/s.

What is the temperature range for this HMI?

The 6AV6641-0BA11-0AX1 is designed to operate in environments with a maximum ambient temperature of 50°C, making it suitable for various industrial applications.

What certifications does the 6AV6641-0BA11-0AX1 hold?

This HMI is certified by multiple standards bodies, including CE, GL, ABS, BV, DNV, LRS, FM Class I Div. 2, UL, CSA, and cULus, ensuring compliance with global industry standards.

What is the IP rating of this HMI?

The front panel is IP65 for dust and water resistance, while the rear panel is IP20. This combination provides robust protection for industrial environments.

What is included in the warranty?

MRO Electric and Supply offers a 2-year warranty on the product, which covers manufacturing defects and potential issues that may arise within the warranty period.

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry HMIs from other manufacturers such as FANUC and Yaskawa.
