Siemens 3TH2022-0BG4

Siemens 3TH20220BG4 Contactor Relay

The Siemens 3TH20220BG4 is a high-quality contactor relay widely used in industrial automation and control applications. Though now discontinued by the manufacturer, it remains a reliable electrical switching and control operation solution. This model is designed to meet DIN EN 50011 standards, ensuring compliance with industry regulations. It operates on 125 VDC, making it suitable for various industrial and commercial applications where precise control of electrical circuits is required. With durable construction and reliable performance, the 3TH20220BG4 has been preferred for many automation and control systems.

Electrical Configuration and Features

The Siemens 3TH20220BG4 is designed with a 22E contact configuration consisting of two normally open (NO) and two normally closed (NC) contacts. This configuration provides versatility in controlling electrical circuits, allowing it to be used in various applications, such as motor control, signal switching, and automation. The contactor relay features screw terminals for secure and stable connections, ensuring minimal resistance and optimal performance. Its robust design makes it a dependable component for industrial control systems.

DC Operation for Reliable Performance

Operating on 125 VDC, the 3TH20220BG4 provides reliable switching performance in direct current applications. DC operation ensures stable and consistent relay performance, making it suitable for use in environments where fluctuations in power supply must be minimized. This feature is handy in critical industrial applications, such as control panels, power distribution, and automated manufacturing processes, where precision and reliability are paramount.

Compact and Durable Design

Engineered to meet DIN EN 50011 standards, the Siemens 3TH20220BG4 contactor relay is compact yet highly durable. Its construction ensures long-lasting operation, even in demanding industrial environments. The relay is designed for easy installation on DIN rail systems, simplifying integration into control panels and other automation setups. Its durable housing and high-quality internal components contribute to extended operational life, reducing the need for frequent replacements and maintenance.

Warranty and Immediate Availability

Despite being discontinued by Siemens, the 3TH20220BG4 is still available for purchase through MRO Electric and Supply. The product comes with a two-year warranty, assuring its quality and reliability. This availability ensures that businesses using this contactor relay can maintain their existing systems without needing immediate redesign or costly upgrades. MRO Electric and Supply offers prompt shipping and expert support to assist customers with their industrial automation needs.

Frequently Asked Questions (FAQs)

What is the Siemens 3TH20220BG4 used for?

It is a contactor relay controlling electrical circuits in industrial automation and power distribution systems.

What type of contacts does this relay have?

It has a 22E configuration, which includes two normally open (NO) and two normally closed (NC) contacts.

What voltage does this relay operate on?

It operates on 125 VDC, making it suitable for direct current applications.

Is this model still being manufactured?

No, Siemens has discontinued it, but it is still available for purchase through MRO Electric and Supply.

What type of terminals does this relay have?

It features screw terminals for secure and stable connections.

Can this relay be mounted on a DIN rail?

It is designed to be easily installed on DIN rail systems for convenient integration.

What standards does this relay comply with?

It meets DIN EN 50011 standards, ensuring compliance with industry regulations.

Is there a warranty on this product?

MRO Electric and Supply offers a two-year warranty on the Siemens 3TH20220BG4.

Where can I purchase this relay?

It is available through MRO Electric and Supply, with immediate shipping options.

What industries commonly use this relay?

It is commonly used in industrial automation, power distribution, motor control, and signal-switching applications.

Siemens products are manufactured in Germany and are designed for Automotive, aerospace, power generation, and electronics usage. They come with a 2-year warranty from MRO Electric. We also carry Contactors from other manufacturers such as FANUC and Yaskawa.
