Schneider Electric 171CCC76010

Schneider Electric 171CCC76010 CPU

The Schneider Electric 171CCC76010 CPU is a powerhouse designed to drive automation processes with precision and efficiency. As a crucial component of the Modicon Momentum automation platform, this M1/M1E processor adaptor offers unparalleled performance and versatility, making it an ideal choice for various industrial applications.

Robust Design and Compatibility:

The 171CCC76010 CPU is crafted with durability. It boasts a sturdy construction using Lexan material. With a width of 4.92 inches (125 mm), it seamlessly integrates into existing automation systems. It is compatible with leading software designations such as Concept V2.6, Modsoft V2.5, ProWORX 32, and ProWORX NxT V2.0, ensuring smooth integration and seamless operation.

Powerful Processor and Memory Capacity:

At its core lies an X86-based processor (INTEL, AMD) with a clock frequency of 32 MHz, providing robust computational power for complex automation tasks. The 171CCC76010 CPU offers an impressive discrete I/O processor capacity of 8192 inputs and 8192 outputs, along with extensive memory resources, including Flash memory of 512 kB and RAM of 512 kB. With a memory type comprising Flash and RAM, it ensures reliable data storage and processing.

High-Speed Communication and Versatile Protocol:

Equipped with a communication port protocol supporting Modbus, the 171CCC76010 CPU facilitates seamless data exchange and communication between various industrial devices and systems. Its precise and efficient communication capabilities enable real-time monitoring and control of automation processes.

Efficient Performance and Precise Timing:

With an exact time of 1 millisecond for executing 1 K instruction, the 171CCC76010 CPU ensures swift and accurate execution of automation commands. Its registered I/O processor capacity of 26048 inputs and 26048 outputs and an I/O limit processor capacity of 8192 bits max ensures comprehensive control over industrial processes.

User-Friendly Interface and Easy Installation:

The 171CCC76010 CPU features a single I/O bus and one RS232C non-isolated port, simplifying connectivity and setup. Its user-friendly interface and intuitive design streamline configuration and programming tasks, enabling operators to optimize automation processes easily.

Reliable Supply Voltage and Robust Performance:

Operating at a rated supply voltage of 5.0 V DC with a +/- 5% tolerance, the 171CCC76010 CPU ensures stable and consistent performance even in demanding industrial environments. Its robust design and high-quality components guarantee reliability and longevity, minimizing downtime and enhancing productivity.

FAQs about the Schneider Electric 171CCC76010 CPU:

What is the Schneider Electric 171CCC76010 CPU?

The 171CCC76010 CPU is a processor adaptor designed for industrial automation applications. It is a crucial component of the Modicon Momentum automation platform, providing computational power and communication capabilities for controlling various industrial processes.

What are the key features of the 171CCC76010 CPU?

The 171CCC76010 CPU features an X86-based processor with a clock frequency of 32 MHz, extensive memory capacity including Flash and RAM, support for Modbus communication protocol, and compatibility with leading software designations such as Concept, Modsoft, ProWORX 32, and ProWORX NxT.

What is the memory capacity of the 171CCC76010 CPU?

The 171CCC76010 CPU offers 512 kB of Flash memory and 512 kB of RAM. It also includes program memory of 18 kB (LL984) and 240 kB (IEC), providing ample storage for data and programming instructions.

What communication protocols are supported by the 171CCC76010 CPU?

The 171CCC76010 CPU supports the Modbus communication protocol, facilitating seamless data exchange and communication between industrial devices and systems.

How does the 171CCC76010 CPU ensure precise timing and efficient performance?

With an exact time of 1 millisecond for executing 1 K instruction, the 171CCC76010 CPU ensures swift and accurate execution of automation commands. Its high-speed communication capabilities and extensive memory resources further enhance performance.

Is the 171CCC76010 CPU easy to install and integrate into existing systems?

The 171CCC76010 CPU features a user-friendly interface and seamless compatibility with leading software designations, making integrating into existing industrial automation systems easy. Its robust construction and compact design simplify installation procedures.

What are the benefits of using the 171CCC76010 CPU in industrial automation applications?

The 171CCC76010 CPU offers reliable performance, precise timing, seamless communication, extensive memory capacity, and compatibility with leading software platforms. It empowers industries to optimize automation processes, enhance productivity, and minimize downtime.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry CPUs from other manufacturers such as Modicon and ABB.
