170INT11003

2-year Warranty

Same Day Shipping

Schneider Electric 170INT11003

MODICON MOMENTUM INTERBUS COMMUNICATION ADAPTOR - TWISTED PAIR

5/5
2 ratings

Select Condition

Refurbished

2 in stock

New

2 in stock

$265.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number170INT11003
ManufacturerSchneider Electric
TypeAccessories
Model #170-INT-110-03
Warranty2 Year
Module formatStandard
Range of productModicon Momentum automation platform
Product or component typeInterbus communication adaptor
Communication port protocolInterbus generation SUPI 3
Method of accessMaster/Slave
Continuous shift register
Transmission rate500 kbit/s
Transmission support mediumTwisted pair
TopologyRing
Number of devices0...254
Cable length<= 41994.75 ft (12800 m)
<= 1312.34 ft (400 m) between two modules
Fail stateFail safe
Control parameterCRC-16
SupplyFrom I/O base
MarkingCE
Local signalling1 LED bus enable (BA)
1 LED logic power check (UL)
1 LED remote bus check (RC)
1 LED remote bus disabled (RD)
Electrical connection2 connectors SUB-D 9 for connecting Interbus

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 170INT11003 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 170INT11003 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 170INT11003, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 5 hours and 46 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 170INT11003 for credit when ordering from MRO Electric

MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 170INT11003 Overview

Schneider Electric 170INT11003

The Schneider Electric 170INT11003, a key component within the Modicon Momentum automation platform, stands as a robust Interbus communication adaptor, meticulously engineered for precision and reliability. This technical description delves into the detailed specifications and features that define the 170INT11003, providing a comprehensive insight into its capabilities within industrial automation.

Product Overview

Part Number: 170INT11003

Manufacturer: Schneider Electric

Type: Interbus Communication Adaptor

Communication Protocol

The 170INT11003 operates under the Interbus generation SUPI 3 communication protocol, showcasing Schneider Electric's commitment to compatibility and adherence to industry standards. It utilizes a master/slave access method combined with continuous shift register architecture, ensuring seamless communication in industrial networks.

Transmission Rate and Medium

With a transmission rate of 500 kbit/s, the 170INT11003 facilitates high-speed data transfer critical for real-time industrial applications. The communication medium employed is twisted pair, a reliable and common transmission medium known for its noise resistance and signal integrity.

Topology and Scalability

Configured in a ring topology, the 170INT11003 supports up to 254 devices per segment. This scalability allows for the integration of a multitude of devices within a network, catering to the evolving needs of industrial setups.

Maximum Cable Distance and Fail-Safe Operation

The communication adaptor offers an extensive maximum cable distance of 41994.75 ft (12800 m) between devices, emphasizing its suitability for large-scale industrial networks. In case of failures, the module is designed with fail-safe mechanisms, ensuring system reliability even in challenging conditions.

Control Parameters and Supply

Control parameters are managed through a CRC-16 mechanism, contributing to data integrity and error detection. The module draws its supply from the I/O base, simplifying power distribution within the system.

Local Signaling and Electrical Connection

Local signaling is facilitated through LEDs, providing visual cues for bus enable (BA), remote bus check (RC), remote bus disabled (RD), and logic power check (UL). The electrical connection is established through two SUB-D 9 connectors, offering a standardized and reliable interface for connecting Interbus.

Weight and Certification

With a net weight of 0.15 lb(US) (0.07 kg), the 170INT11003 is lightweight yet robust, contributing to ease of installation and minimizing system load. Certified by FM Class 1 Division 2, CSA, and UL, the module meets stringent industry standards for safety and reliability.

Environmental Considerations

The module is designed to withstand challenging environmental conditions. With an IP20 degree of protection, protective treatment against environmental factors, and resistance to electrostatic discharge and electromagnetic fields, it ensures reliable performance in diverse industrial settings.

Operational Parameters and Compliance

Operating within an ambient air temperature range of 32 to 140 °F (0 to 60 °C), the 170INT11003 demonstrates adaptability to varying industrial environments. It complies with REACh regulation, EU RoHS directive, and China RoHS regulation, reaffirming Schneider Electric's commitment to environmental responsibility.

In conclusion, the Schneider Electric 170INT11003 stands as a testament to precision and reliability within industrial automation. As a crucial component in the Modicon Momentum automation platform, this Interbus communication adaptor showcases advanced communication capabilities, scalability, and robust design. With its adherence to industry standards and certifications, the 170INT11003 is a reliable solution for seamless data exchange in industrial networks, ensuring the efficiency and integrity of automation processes.

Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry Accessories from other manufacturers such as Modicon and ABB.
