MODICON MOMENTUM ETHERNET COMMUNICATION ADAPTOR - 10/100 MBIT/S
| Part Number | 170ENT11001 |
| Manufacturer | Schneider Electric |
| Type | Accessories |
| Model # | 170-ENT-110-01 |
| Warranty | 2 Year |
| Module format | Standard |
| Range of product | Modicon Momentum automation platform |
| Product or component type | Ethernet TCP/IP communication adaptor |
| Communication port protocol | Ethernet TCP/IP |
| Method of access | Master/Slave |
| Peer to peer | |
| Transmission rate | 10/100 Mbit/s |
| Transmission support medium | Shielded twisted pairs cable |
| Module configuration | BOOTP server to assign IP parameters |
| Topology | Multidrop, star network |
| Port Ethernet | 100BASE-TX |
| Number of devices | >= 0 with hub or repeater |
| 0...32 per segment | |
| Cable length | >= 3280.84 ft (1000 m) with repeater |
| 3280.84 ft (1000 m) without repeater |
| Addressing | IP address user assigned |
| Unique IEEE global address | |
| Fail state | Fail safe |
| Control parameter | CRC-32 |
| Supply | From I/O base |
| Marking | CE |
| Local signalling | 1 LED green Ethernet network 10 Mbits/s (10T) |
| 1 LED green Ethernet network state (ST) | |
| 1 LED green module active (RUN) | |
| 1 LED yellow Ethernet network 10 Mbits/s (100T) |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 170ENT11001 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 170ENT11001 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 170ENT11001, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped tomorrow?
Ask about exchanging your faulty 170ENT11001 for credit when ordering from MRO Electric
The Modicon 170ENT11001 stands as a pivotal component within the Modicon Momentum automation platform, exemplifying precision and efficiency in Ethernet communication. This technical description delves into the key specifications and features that make the 170ENT11001 a robust Ethernet TCP/IP communication adaptor designed for industrial automation.
Product Overview
Product Name: Modicon 170ENT11001
Product Type: Ethernet TCP/IP Communication Adaptor
Transmission Rate: 10/100 Mbit/s
The 170ENT11001 is engineered to adhere to Ethernet TCP/IP communication standards, making it a cornerstone for seamless data exchange in industrial networks. Its peer-to-peer and master/slave access methods underscore its versatility in accommodating diverse communication architectures within the industrial automation landscape.
With a transmission rate of 10/100 Mbit/s, this communication adaptor ensures swift and reliable data transfer. The use of shielded twisted pairs cable as the transmission medium further enhances signal integrity, crucial for maintaining communication precision in industrial environments.
Equipped with a BOOTP server for IP parameter assignment, the 170ENT11001 supports multidrop and star network topologies. This flexibility in module configuration empowers users to adapt the communication setup to the specific needs of their automation processes.
The 170ENT11001 offers scalability with a capacity to connect 0 to 32 devices per segment. This scalability is vital for accommodating varying network sizes, ensuring adaptability in different industrial setups.
The communication adaptor supports a maximum cable distance of 3280.84 ft (1000 m) between devices without the need for repeaters. Addressing is facilitated through a unique IEEE global address, with the option for user-assigned IP addresses.
Control parameters, specifically CRC-32, contribute to data integrity and error detection in communication. The 170ENT11001 is designed with fail-safe mechanisms, ensuring continuity and reliability in operation even in challenging conditions.
Local signaling is provided through LEDs, offering real-time feedback on network and module status. LEDs for Ethernet network state at both 10 Mbit/s and 100 Mbit/s, module activity, and network state provide visual cues for efficient diagnostics and monitoring.
The electrical connection is facilitated through an RJ45 connector for 100BASE-TX, a standard in Ethernet communication. The lightweight design, with a net weight of 0.15 lb(US) (0.07 kg), enhances ease of installation and integration into existing systems.
Certified by CSA and UL, the 170ENT11001 meets rigorous industry standards. With an IP20 degree of protection, protective treatment against environmental factors, and resistance to electrostatic discharge and electromagnetic fields, it ensures robust performance even in challenging industrial environments.
The 170ENT11001 operates within an ambient air temperature range of 32 to 140 °F (0 to 60 °C) and can withstand storage temperatures ranging from -40 to 185 °F (-40 to 85 °C). It is designed to operate in environments with up to 95% relative humidity without condensation and at altitudes up to 16404.2 ft (5000 m).
In conclusion, the Modicon 170ENT11001 Ethernet TCP/IP communication adaptor is a testament to precision and reliability within industrial automation. Its adherence to communication standards, scalability, fail-safe operation, and robust environmental specifications make it a vital component for seamless data exchange in modern industrial networks. As a key player in the Modicon Momentum automation platform, the 170ENT11001 excels in facilitating efficient and secure communication in diverse industrial applications.
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machine usage. They come with a 2-year warranty from MRO Electric. We also carry Accessories from other manufacturers such as Modicon and ABB.
