2 in stock
Ships Today
Free Shipping
2 Year warranty
| Part Number | 170AEC92000 |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | 170-AEC-920-00 |
| Warranty | 2 Year |
| Current consumption | 125 mA 120 V |
| Range of product | Modicon Momentum automation platform |
| Product or component type | High speed counter module base |
| Group of channels | 2 groups of 2 discrete outputs |
| 2 groups of 3 discrete inputs | |
| Number of counter | 2 |
| Discrete input number | 6 |
| Discrete output number | 4 |
| Discrete input logic | Positive |
| Discrete input voltage | - 3...30 V DC |
| 24 V DC | |
| Maximum overvoltage on input | 45 V 10 s |
| Voltage state 1 guaranteed | >= 11 V |
| Voltage state 0 guaranteed | <= 5 V |
| Current state 1 guaranteed | >= 2.5 mA |
| Current state 0 guaranteed | <= 1.2 mA |
| Discrete output logic | Positive |
| Discrete output voltage | 24 V |
| Discrete output current | 1 A per counter |
| 2 A per module | |
| 0.5 A per point | |
| Voltage drop | < 0.5 V 0.5 A at state on |
| Leakage current | < 1 mA DC 24 V |
| Surge current | 5 A 1 ms |
| Response time | < 0.1 ms from state 0 to state 1 output circuit |
| < 0.1 ms from state 1 to state 0 output circuit | |
| 3 ms from state 0 to state 1 input circuit | |
| 3 ms from state 1 to state 0 input circuit | |
| Counting input type | Absolute SSI up, down with 4 sub-modes |
| Incremental up, down, quadrature | |
| Counting input voltage | 24 V single ended |
| 5 V differential | |
| Counting frequency | <= 10 kHz single ended |
| <= 200 kHz differential | |
| Counter inputs resolution | 24 bits + sign |
| Counter configuration | Via comm adapter |
| Marking | CE |
| Electrical connection | 2 connectors for removable terminal blocks |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 170AEC92000 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 170AEC92000 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 170AEC92000, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 170AEC92000 for credit when ordering from MRO Electric
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
Check out the rest of our Schneider Electric product line. Whether it's using our online instant quote feature, giving us a call at (800) 691-8511, or emailing us at sales@mroelectric.com, we strive for customer satisfaction first. This means lower prices and better service for you. For more products like 170AEC92000, take a look at more from our I/O Modules line. If your current unit has gone bad, take advantage of our Core Exchange program for the most inexpensive route. You can learn more about this program on our FAQ page here. We offer a repair service on all of our 170AEC92000 products that keep your downtime to a minimum. To stay up to date on manufacturer news, as well as access any of our datasheets, manuals, or other documentation, we suggest you take a look at our blog.
