MODICON QUANTUM MODULE TCP / IP
Available
Free Shipping
2 Year warranty
| Part Number | 140NOC77100 |
| Manufacturer | Schneider Electric |
| Type | I/O Modules |
| Model # | 140-NOC-771-00 |
| Warranty | 2 Year |
| Marking | CE |
| Product or component type | Ethernet/IP network module |
| Product compatibility | All Unity CPU |
| Communication port protocol | Ethernet/IP |
| Maximum number of connections | 128 |
| Transmission rate | 10/100 Mbit/s |
| Redundancy | No standalone |
| Communication service | SNMP agent |
| CIP implicit messaging (I/O communication) | |
| CIP Explicit messaging (client messaging) | |
| DHCP/BootP server | |
| Transmission support medium | Twisted pair |
| Port Ethernet | 10BASE-T/100BASE-TX, connector type: RJ45 |
| Marking | CE |
| Supply | Via the power supply of the rack |
| Local signalling | 1 LED green for communication on the bus (Active) |
| 1 LED green for configuration status (Ready) | |
| 1 LED green for connection speed (100MB) | |
| 1 LED green for Ethernet network status (link) | |
| 1 LED green/red for full duplex/collision detection (Fduplex/Col) | |
| 1 LED green for reception activity (RxActive) | |
| 1 LED green for transmission activity (TxActive) | |
| 1 LED green/red for module status (Mod Status) | |
| 1 LED green/red for network communication status (Net Status) | |
| Current consumption | 500 mA at 5 V DC |
| Module format | Standard |
MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.
MRO can restore your failed 140NOC77100 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.
Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.
Our technicians have vast experience with most manufacturers and models. In addition to this 140NOC77100 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.
If you are interested in getting credit for your faulty 140NOC77100, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.
Want it shipped today?
Ask about exchanging your faulty 140NOC77100 for credit when ordering from MRO Electric
The Schneider Electric 140-NOC-771-00 Ethernet/IP Network Module is a versatile and robust communication module designed to optimize the connectivity and performance of automation systems. Compatible with all Unity CPUs, it is engineered for seamless integration into industrial settings, providing reliable Ethernet/IP communication capabilities. With a 10/100 Mbps transmission rate over twisted pair cabling, this module ensures fast and stable data transfer, supporting up to 128 simultaneous connections. Its compact, standard module format makes installation straightforward, while its efficient power consumption—drawing 500 mA at 5 V DC—aligns with the demands of modern industrial environments.
This module boasts comprehensive communication services, including SNMP agent functionality, DHCP/BootP server, and CIP messaging for implicit (I/O communication) and explicit (client messaging) exchanges. Its dual Ethernet ports, compliant with 10BASE-T/100BASE-TX standards and equipped with RJ45 connectors, enhance communication efficiency and reliability. While the module does not support standalone redundancy, its robust design and advanced networking features ensure dependable operation for various industrial applications.
Equipped with an array of local signaling LEDs, the 140-NOC-771-00 simplifies monitoring and diagnostics. LEDs indicate critical operational statuses, such as communication on the bus, configuration readiness, connection speed, Ethernet network status, reception and transmission activities, and module/network communication health. This real-time feedback allows technicians to quickly identify and address issues, minimizing downtime.
The module adheres to CE marking standards, ensuring compliance with European regulations and underscoring its reliability and quality. Backed by a two-year MRO Electric and Supply warranty, the 140-NOC-771-00 offers long-term peace of mind and exceptional value. Free shipping makes this product an even more attractive choice for businesses seeking cost-effective, high-performance Ethernet/IP communication solutions.
What is the primary application of the 140-NOC-771-00 module?
The module establishes Ethernet/IP communication for automation systems equipped with Unity CPUs, enabling efficient data exchange and networking.
What types of communication services does this module support?
It supports SNMP agents, CIP implicit and explicit messaging, DHCP/BootP server functionalities, and Ethernet/IP protocols.
Can the module be used with any Unity CPU?
The module is compatible with all Unity CPUs, ensuring broad applicability across various system setups.
What is the transmission rate of the module?
The module operates at 10 and 100 Mbps, ensuring fast and reliable communication.
What kind of Ethernet ports does the module have?
It features two RJ45 Ethernet ports that are compliant with 10BASE-T and 100BASE-TX standards.
Does the 140-NOC-771-00 support redundant operation?
The module does not support standalone redundancy, but it is designed for reliable performance in non-redundant setups.
What are the power supply requirements for this module?
It is powered via the rack's power supply, drawing 500 mA at 5 V DC.
What makes the LED indicators worthwhile?
The LEDs provide real-time status updates, simplifying diagnostics and allowing for quick identification of potential issues.
Is this module CE-marked?
The module complies with CE standards, signifying its adherence to European safety and performance regulations.
What is the warranty coverage for the 140-NOC-771-00?
The module has a two-year MRO Electric and Supply warranty, ensuring product reliability and customer satisfaction.
Schneider Electric products are manufactured in France and are designed for Material handling, packaging, and textile machines usage. They come with a 2-year warranty from MRO Electric. We also carry I/O Modules from other manufacturers such as Modicon and ABB.
