Schneider Electric 140DDO36400

Schneider Electric 140DDO36400: High-Density DC Discrete Output Module

Overview: The Schneider Electric 140DDO36400 is an advanced DC discrete output module that provides reliable and efficient control over multiple devices in industrial automation applications. Its high-density configuration and robust features offer seamless integration and precise control over connected equipment.

Module Format and Type:

Built-in a standard module format, the 140DDO36400 is compatible with various industrial setups, ensuring easy installation and configuration. It functions as a DC discrete output module, offering precise control over connected devices for enhanced automation capabilities.

Discrete Output Capacity:

This module features 96 discrete output channels organized into six groups of 16, providing extensive control options for industrial systems. Each group operates independently, allowing for flexible configuration and efficient management of connected devices.

Output Logic and Addressing:

The discrete outputs operate on negative logic (sink), ensuring compatibility with various industrial control systems. The module's addressing requirement of 6 output words facilitates efficient communication and control within the automation network.

Output Voltage and Current Limits:

The 140DDO36400 module provides a stable output voltage of 24 V DC within 19.2 to 30 volts, ensuring reliable power delivery to connected devices. Each output point can handle a maximum load current of <= 0.5 A, with a total module load capacity of <= 19.2 A.

Protection and Reliability:

Equipped with built-in short-circuit and overload protection mechanisms, the module ensures the safety and integrity of connected devices. It also features surge current protection, response times of <= 0.1 ms, and leakage current of 1 mA at 24 V, enhancing system reliability and performance.

Fault Indication and Reporting:

The module provides comprehensive fault indication and reporting capabilities, including fault point detection, loss of field power, and fault sensing. This allows for quick identification and resolution of issues, minimizing downtime and optimizing productivity.

Isolation and Communication:

With 500 Vrms DC isolation between channels and the bus, the module ensures reliable and secure operation in industrial environments. It also features local signaling indicators, including green LEDs for bus communication and external fault detection.

Power Requirements and Efficiency:

Operating with a power dissipation of 7 W and a bus current requirement of <= 250 mA, the module delivers efficient power management while minimizing energy consumption. This results in reduced operating costs and improved overall system efficiency.

Compliance and Marking:

The 140DDO36400 module bears the CE marking, indicating compliance with European safety and quality standards. This ensures that it meets regulatory requirements and delivers consistent performance in industrial environments.

Frequently Asked Questions

Q: What is the Schneider Electric 140DDO36400 module used for?

A: The Schneider Electric 140DDO36400 is a DC discrete output module primarily used for industrial automation applications. It provides precise control over multiple devices, allowing users to manage various processes efficiently.

Q: How many discrete output channels does the Schneider Electric 140DDO36400 module have?

A: The 140DDO36400 module features 96 discrete output channels organized into six groups of 16. This high-density configuration offers extensive control options for industrial systems.

Q: What type of logic does the Schneider Electric 140DDO36400 module operate on?

A: The 140DDO36400 module operates on negative logic (sink), making it compatible with various industrial control systems. This logic allows for efficient communication and control within the automation network.

Q: Does the Schneider Electric 140DDO36400 module protect connected devices?

A: Yes, the 140DDO36400 module is equipped with built-in short-circuit and overload protection mechanisms to ensure the safety and integrity of connected devices. It also features surge current protection and leakage current detection.

Q: What is the power dissipation of the Schneider Electric 140DDO36400 module?

A: The 140DDO36400 module dissipates 7 watts, ensuring efficient power management while minimizing energy consumption. This contributes to reduced operating costs and improved system efficiency.

Q: Is the Schneider Electric 140DDO36400 module compliant with safety standards?

A: The 140DDO36400 module bears the CE marking, indicating compliance with European safety and quality standards. This ensures that it meets regulatory requirements and delivers consistent performance in industrial environments.
