140CRA93100

2-year Warranty

Same Day Shipping

Schneider Electric 140CRA93100

MODICON QUANTUM ADAPTOR RIO REMOTE ADAPTOR MODULE MODICON QUANTUM -DROP MODULE, 1 CONNECTOR WITH SINGLE CABLE, BUS CURRENT REQUIRED 600 MA

5/5
5 ratings

Select Condition

Refurbished

4 in stock

New

21 in stock

$611.00

Request a formal quote

  • Ships Today
  • 2 Year Warranty
  • Free Shipping
Part Number140CRA93100
ManufacturerSchneider Electric
TypeI/O Modules
Model #140-CRA-931-00
Warranty2 Year
Height50 mm
Product or component typeRIO drop adaptor module
Product compatibilityQuantum
Number of I/O expansion module<= 27
Type of cableCoaxial 75 Ohm
Transmission rate1544 Mbit/s
Dynamic range35 dB
Isolation voltage500 V DC coaxial center and ground
Electrical connection1 female connector F elbowed with single cable
Diagnostics startupExecutive checksum
Power up and runtime
RAM address/data
Power dissipation in W3 W 1 channel
Bus current requirement600 mA 1 channel

Our Repair Services

MRO Electric repairs CNCs, PLCs, Servo/Spindle Drives, Motors, Amplifiers, VFDs, HMIs, and more, most of which can be repaired in only 3-5 days.

Repair Benefits

MRO can restore your failed 140CRA93100 to remanufactured condition and save you up to 75% compared to buying new. We offer standard repair pricing to ensure you the best value for your repair.

Our certified technicians use rigorous testing procedures to ensure your parts are restored to fully functioning condition. Our team proudly stands behind all repairs by providing a minimum 2-year warranty.

Our technicians have vast experience with most manufacturers and models. In addition to this 140CRA93100 we also repair drives, motors, PLCs and more, so if you don’t see the model you need, please contact us.

Core Exchange

If you are interested in getting credit for your faulty 140CRA93100, just let us know, and we can issue you an RMA to send it in as an exchange. Our exchange program provides you with savings and keeps us stocked for the next time you need anything.

  • Shipping Weight : 1lb

Want it shipped today?

  • Order within the next 2 hours and 30 minutes.
  • If you order between 4pm and 6pm EST, you will be charged a small rush fee.

Ask about exchanging your faulty 140CRA93100 for credit when ordering from MRO Electric

A fault light appears to be on my 140CRA93100, what does it mean?

  • The card is not seeing one or more of the IO modules configured for the drop. A module could be in the wrong slot or missing, it also could mean that it has failed. If the IO module is functioning correctly, the word "Active" will appear at the top of the module. If none of the IO modules are "Active" it could be that the address switches at the back of the CRA are not set up correctly. If all modules have the word 'Active', it could be that the Power Supply model number that is in the slot does not match the one in the configuration.

A fault light appears to be on my 140CRA93100, what does it mean?

  • The card is not seeing one or more of the IO modules configured for the drop. A module could be in the wrong slot or missing, it also could mean that it has failed. If the IO module is functioning correctly, the word "Active" will appear at the top of the module. If none of the IO modules are "Active" it could be that the address switches at the back of the CRA are not set up correctly. If all modules have the word 'Active', it could be that the Power Supply model number that is in the slot does not match the one in the configuration.
MRO Electric provides a 2-year warranty on every item we sell and repair. We stand behind all of our products and guarantee them for the full 2 years. If there is an issue with any of our products within the warranty period, we will evaluate the unit and repair or replace it under warranty.

Schneider Electric 140CRA93100 Overview

Schneider Electric 140CRA93100 RIO Drop Adaptor Module

The Schneider Electric 140CRA93100 is a RIO (Remote I/O) drop adaptor module designed for use within Quantum automation systems. It is a critical component in industrial control networks, allowing remote I/O drops to communicate efficiently with the central processor. This module is specifically engineered for high-speed data transmission, supporting a transmission rate of 1544 Mbit/s over 75-ohm coaxial cable, ensuring seamless communication across industrial environments.

Efficient Data Transmission and Network Expansion

The 140CRA93100 supports the integration of up to 27 I/O expansion modules, making it highly scalable for large automation setups. Its dynamic range of 35 dB and isolation voltage of 500 V DC between the coaxial center and ground provide robust signal integrity and protection from electrical interference. This allows for stable, long-distance communication without compromising data accuracy. The module uses a single female F-elbowed connector with a single coaxial cable, simplifying installation while maintaining high-performance connectivity.

Advanced Diagnostic and Power Efficiency Features

The 140CRA93100 includes built-in diagnostic capabilities that ensure system reliability. It performs executive checksum verification, power-up and runtime diagnostics, and RAM address/data checks, allowing for early detection of potential issues. With a power dissipation of only 3W on a single channel and a bus current requirement of 600 mA, this module offers an energy-efficient solution for remote I/O applications.

Seamless Integration and Immediate Availability

Schneider Electric has designed the 140CRA93100 for seamless integration into Quantum automation systems, ensuring compatibility and ease of use. It is an excellent choice for industries looking to expand their control networks with a reliable, high-speed communication module. Available from MRO Electric and Supply, this module comes with a 2-year warranty, free shipping, and immediate availability, ensuring minimal downtime and quick deployment.

Frequently Asked Questions (FAQ)

What is the primary function of the 140CRA93100 module?

The 140CRA93100 is an RIO drop adaptor module that facilitates communication between a Quantum processor and remote I/O expansion modules, ensuring seamless data transfer in an industrial automation system.

How many I/O expansion modules can this module support?

The 140CRA93100 supports up to 27 I/O expansion modules, making it suitable for complex automation setups requiring extensive input and output capabilities.

What type of cable is required for installation?

This module uses a 75-ohm coaxial cable, which provides high-speed data transmission with reliable signal integrity.

What is the module's data transmission rate?

The 140CRA93100 operates at a transmission rate of 1544 Mbit/s, ensuring fast and efficient communication within industrial automation networks.

What diagnostic features are included in this module?

The module includes executive checksum verification, power-up and runtime diagnostics, and RAM address/data checks, which allow for early detection of issues and maintain system stability.

What is the power dissipation of the module?

The 140CRA93100 dissipates 3W on a single channel, making it an energy-efficient option for automation systems.

What voltage isolation does the module provide?

The module provides a 500 V DC isolation voltage between the coaxial center and the ground, ensuring protection against electrical interference.

What is the bus's current requirement for this module?

The module requires 600 mA on a single channel, ensuring efficient power consumption and system reliability.

How does this module connect within an automation system?

The 140CRA93100 features a single female F-elbowed connector with a single coaxial cable, simplifying installation and maintaining a stable connection.

Is the 140CRA93100 available for immediate purchase?

Yes, MRO Electric and Supply offers the 140CRA93100 with free shipping and immediate availability. It is also backed by a 2-year warranty for added confidence in your purchase.
